Dongfeng Aerial Platform Truck 22m-24m Fully Hydraulically Operate 3 Boom Option 4X2.4X4 LHD. Rhd
Hubei Dong Runze Special Vehicle Equipment Co., Ltd.- Warranty:24
- Type:H
Base Info
- Model NO.:4x2.4x4 LHD. RHD
- Certification:ISO9000, CCC
- Emission Standard:Euro 3
- Hoesrpower:150-250hp
- Payload:16t
- Fuel:Diesel
- Transmission Type:Manual
- Drive Wheel:Option 4X2.4X4 LHD .Rhd
- Condition:New
- Tire:9.00-20, 10.00-20
- Cabin:145,153
- Fuel Tank(L):400L
- Drive:LHD , Rhd
- Work Lift Height:18m, 20m, 22m24m26m
- Boom Crane Loading Capacity:1000kg
- Wheelbase (mm):3950, 4200, 4500, 4700, 5100
- Engine:160HP, 190HP
- Transport Package:Nil
- Specification:OEM
- Trademark:Dongfeng
- Origin:China
- HS Code:8705909990
- Production Capacity:10000
- Package size per unit product:1100.00cm * 255.00cm * 340.00cm
- Gross weight per unit product:8000.000kg
Description
Overview
Technical parametersThe total mass(kg) 10080 Curb Weight(kg) 9885 Rated quality(kg) xx Chassis Model EQ1168VFJ1 Approach / departure angle(°) 23/14 Front/Rear overhang 1250/2050 Dimensions(mm) 9200,8530*2480*3610 Number of spring 9/10+8 Number of axles 2 Maximum speed 90 Tire Specifications 9.00-20,9.00R20 Number of tires 6 Front track 1920,1960 Rear track 1860 Wheelbase(mm) 3800,3950,4200,4500,4700,5100 Axle load 5950/9950 Emission Standards Euro II/Euro III/Euro IV Type of fuel Diesel Engine parameters Engine Model YC6J160-46 Engine Manufacturer Guangxi yuchai machinery Engine Displacement(ml) 6494 Engine power(kw) 118 Modified Description 1. Basic equipment:1.height of working:20-25m,360°all rotation,three folding arms,single hydraulic cylinder,rated load of cage:200-250kg.
2. 1 ton stretch hook,four hydraulic oil cylinder that are adjustable,without emergency power unit.
3. Equipped with two-way balancing valve,ectrical control operation,two sets of operating system. (1set platform pilot switch and 1 set pilot switch in the cab); Basic composition chassis,PTO,gear pump,chassis parts,folding arms/telescopic arms, oil cylinder,pipeline system,working cage, rotating mechanism,hydraulic system,electrical system. Application Convenient moving,used in narrow roads and streets.Aerial work platform can be used in aloft working of electricity,street lamp,municipal administration,gardens,transportation and so on General Vehicle Brand Dong Run Chassis Brand Dongfeng Overall Dimension 9600 * 2500 * 3620 mm GVW / Kerb Weight 15,825 kg / 15,500 kg Cab Cab Capacity 3 persons allowed Air Conditioner Air conditioner is optional Engine Fuel Type Diesel Engine Brand Cummins engine Power 190 Ps (40 KW) Displacement 5900 ml Emission Standard Euro III Chassis Drive Type 4X2, left or right hand drive Transmission 6-speed front, 1 reverse Wheelbase/No. of axle 4700 mm / 2 Tyre Specification 10.00-20 Tyre Number 6 tyres and 1 spare tyre Max Speed 80 km/h Paint Metallic paint Superstructure Working Cage 200 kg capacity, anti-slip floor Working Height ≤24M Slewing 360° continuous rotation with base turntable Control Control both on the ground and in the cage Emergency electrical/manual pump is equipped to operate the equipment in case of engine failure. Emergency stop switches at base and operator's cage. Optional ** Hoist hook with cables can be equipped for the function of a crane.
The pole height is 6M so aerial lift should be 8-10M.
Water tank capacity can be 3000Ltr
Truck may be medium light truck of 3.% ton.
Welcome all around world customer visit our factory
2. 1 ton stretch hook,four hydraulic oil cylinder that are adjustable,without emergency power unit.
3. Equipped with two-way balancing valve,ectrical control operation,two sets of operating system. (1set platform pilot switch and 1 set pilot switch in the cab);
190HP/4x2/4x4
CertificationsPackaging & Shipping
Similar Key Words: hydraulic boomlifter, overhead working truck, truck mounted aerial platform, aerial beam lifter, man lift truck, articulated basket platform, skylift, insulated aerial cage truck
Aerial platform truck 16m water tank and water pump ,Truck Mounted Aerial Work Platform water tank,Work Platform water tank truck,aerial bucket truck water tank,bucket truck with water tank ,Truck Mounted water tank Aerial Work Platform
Truck mounted aerial platform, which will be used to clean pole mounted solar panels for street lights. So it requires a special arrangement of truck mounted water tank as well as water hose at the basket.The pole height is 6M so aerial lift should be 8-10M.
Water tank capacity can be 3000Ltr
Truck may be medium light truck of 3.% ton.
Welcome all around world customer visit our factory
