• Model NO.：water tank truck
• Fuel：Diesel
• Drive Wheel：6×4
• Engine Capacity：6 - 8L
• Condition：New
• Tanker Volumen：20m3
• Drive Type：Left-Hand Drive
• Max. Speed：75km,H
• Curb Weight：12400kg
• Rated Loading Weight：12450kg
• Horse Power：290HP
• Fuel Tanker Capacity：300L
• Steering System：Zf8098
• Tanker Volume：15000L
• Cabin：Hw76
• Transport Package：Nude Packaging
• Specification：9000x2496x2958mm
• Trademark：SINOTRUK
• Origin：Shandong
• Production Capacity：500 PCS , Month

Dimension(Lx W xH)(unloaded(mm)9895×2496×2958Tanker volume(m³)(m³)20m3 Tank body(thickness):5mm,material:carbon steel; sprinkling equipment both in front and in rear; special anti-corrosion treatmentApproaching angle/Departure angle(°)13.5/11.5Overhang(front/rear) (mm)1500/2445Wheel base (mm)4600+1350Max speed(km/h)75Curb weight(kg)12400Rated Loading Weight(kg)12450Engine
(Steyr technology, made in China)ModelWD615.87,water-cooled,four strokes,6 cylinders in line with water cooling,directly injectionFuel typeDieselHorse Power, max(kw/rpm)290HPEmissionEURO 2Fuel tanker capacity (L)300TransmissionModelHW15710, 10 forward, 2 reverseBrake systemService brakeDual circuit compressed air brakeParking brakespring energy, compressed air operating on rear wheelsSteering systemModelZF8098Front axleHF7 , Steering with double T-cross section beamRear axleHW12ColorWhite,Red,Yellow. According to the customerTyre11.00-20Tanker volume15000LElectrical systemBattery2X12V/165AhAlternator28V-1500kwStarter7.5Kw/24VCabHOWO76 cab, (single sleeping, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
