Dust Suppression Water Fog Cannon Tanker Truck Multifunctional Ds-60-100m
Hubei Dong Runze Special Vehicle Equipment Co., Ltd.- After-sales Service:24
- Warranty:12
- Volume:10001 - 15000L
- Certification:ISO9000, CCC
- Emission Standard:Euro 3-5 -6 -7
- Sprinkling Area:>16m
Base Info
- Model NO.:Water Fog Cannon Truck
- Transmission Type:Manual
- Payload:10-18t
- Fuel:Diesel
- Drive Wheel:6×4
- Engine Capacity:4 - 6L
- Condition:New
- Tire:10.00-20, 11.00-20
- Fuel Tank(L):400L
- Transport Package:Nil
- Specification:Dust Suppression Unit
- Trademark:Dong Run Ze
- Origin:China
- HS Code:8705909990
- Production Capacity:10000
Description
Overview
DRZ250TDY5JF multi-function dust suppression vehicleItem Parameter
Working specification
Working SpeedLow pressure washing 8-20km/h Fog spray system 8-20km/h Longest range of water fog spray >120m Water flow rate of fog spray 120~260L/min Longest working time of fog spray 125min Water flow rate of low pressure washing 600~800L/min Low pressure washing width ≥24m Water spray width 14m Water cannon range ≥38m Maximum volume of water tank 15m³ Drive performance Highest speed at full load 94km/h Brake distance(Full load at the speed of 60km/h) ≤36.7m Minimum turning diameter <19.7m
Mass parameterKerb weight 13100kg payload 11900kg GVW 25000kg
Structure SizeOverall dimension(L×W×H) 11830x2500x3900mm
TreadFront wheel 1950mm Rear wheel 1878mm Approach angle 13° Departure angle 9° Min. ground clearance 210mm
ater truck special function
A. Water tank capacity(L):16000L- 20,000 Liters
B. Sprinkling area(m):14-16m
C. Suction lift(m):≥7m
Water cannon range description
Water cannon installed on the rear of the truck,also
with operation platform,that operator can work on
the platform.It can be used to clean road,trees,and
also for emergency fire fighting.
Water cannon range:≥60m,it can rotation with 360°
degree freely
Manhole size(mm)
Man way access hole on top of tank; manhole
diameter:¢500mm
Front spray function
Front spray bar with fan sprayer,spray range: ≥20m
Man walk way
With skid resistance man walk way on top of tank
Water pump model
80QZB(F)-60/90S
Flow rate(L/m)
1000
Head of delivery(m)
60
Shaft power
22.5
Suction height (m)
6.5
Efficiency(%)
95% CertificationsPackaging & ShippingFAQ
2 .Can I have samples of this type of product to test the quality?
Yes, you can buy any sample to test the quality,our MOQ is 1 unit.
3. What's the delivery time and can you lower the price?
It depends on your order.The delivery time is within 30 workdays after we received your prepayment. If you have placed an order of large quantities, then,of course, the price can be lowered.
4.Can you supply some quick-wear parts? Yes, we can supply the parts as your request,such as traction,traction pin,balance beam and plate spring,hanging accessories,turntable,all kinds of brake pads,brake pan, bearings,etc.
6.Do you have any used products for sale? We have products in stock for choices,the prices are favorable,we'll show you our stock products if you need.
7.What's the payment terms?TT 30% as deposit, balance before shipment by TT or at sight.
8. How to guarantee customers get the goods smoothly after they payment?
Don't worry,dear.We have joined the trade assurance,you can place the order by trade assurance,if we don't delivery products, the deposit will be returned to you.
9.How can you ensure the quality of the products?
Working specification
Working Speed
Mass parameter
Structure Size
Tread
ater truck special function
A. Water tank capacity(L):16000L- 20,000 Liters
B. Sprinkling area(m):14-16m
C. Suction lift(m):≥7m
Water cannon range description
Water cannon installed on the rear of the truck,also
with operation platform,that operator can work on
the platform.It can be used to clean road,trees,and
also for emergency fire fighting.
Water cannon range:≥60m,it can rotation with 360°
degree freely
Manhole size(mm)
Man way access hole on top of tank; manhole
diameter:¢500mm
Front spray function
Front spray bar with fan sprayer,spray range: ≥20m
Man walk way
With skid resistance man walk way on top of tank
Water pump model
80QZB(F)-60/90S
Flow rate(L/m)
1000
Head of delivery(m)
60
Shaft power
22.5
Suction height (m)
6.5
Efficiency(%)
95%
