• Model NO.：CS
• Fuel：Diesel
• Drive Wheel：4×2
• Brand：Dongfeng
• Models：Small
• Usage：Dump, Swing Arm Type, Sealed, Hang Barrel Type, Arm Type, Compression Type, Eat Hutch Type
• Condition：New
• Product Name：HOWO 4X2 8m3 Garbage Truck Used Garbage Truck
• Driving Type：Left Hand Drive , Right Hand Drive
• Loading Capacity：6m3 8m3 10m3 12m3 15m3 20m3
• Garbage Truck Type：Compactor Rear Loader Recycling Roll
• Color：Blue White as Customer′s Request
• Truck Brand：Dongfeng FAW Foton Sinotruk JAC Isuzu
• Truck Drive Wheel：4X2 6X4 8X4
• Emission Standardruck：Euro II
• Certifications：ISO9001 CCC ISO
• Applications：Transport a Variety of Garbages and Bulk Material
• Transport Package：Nake Package RO-RO Ship Container Ship
• Specification：11980*2600*3620mm
• Trademark：Chusheng
• Origin：China
• HS Code：8705909990
• Production Capacity：50000

Product nameDongfeng 6cbm hydraulic garbage compactor truck/refuse garbage truckDustin volume(m³)6~7Chassis modelDFA1080SJ11D3Overall dimension(mm)7390×2350×2850Brand nameDongfengGross weight(Kg)8495Wheelbase(mm)3800Payload(Kg)2000Drive type4*2Curb weight(Kg)6300Fuel typeDieselAxle No.2Emission standardEuro 2/Euro 3/Euro 4Cab seats(person)3Transmission5-speedApproach/departure angle(°)24/13Tires No.6Axle load (Kg)3390/5105Tire specification7.50-16Front/rear hang(mm)1210/2380Max speed(km/h)95Front/Rear track(mm)1845/1680Steel spring number8/10+7Engine parametersEngine modelEngine manufacturerDisplacement (ml)power(kw)CY4102-CE4BDongfeng chaoyang forward power co ., LTD3856100Chassis DescriptionDongfeng 4x2 chassis, single row and left/right hand drive optional,136HP Engine.tandard Equipment1. Dustbin volume: 6~7m³, it is made of carbon steel plate.
2. Equipped with front push back pressure, vice press plate, sewage box, electric control operation. Compressed dustbin is couplet body type, external power source work, overturn feedstock, compression push board in dustbin, rear lock door and tipping bucket, hydraulic electric system and etc.
3.Garbage compactor truck adopt machine,electricity,liquid linkage control system, computer control and manual operation system, realize rubbish into,crush or press flat through loading device and push shovel, and then squeeze garbage into the dustbin, compaction and push unloading.
4.The garbage compactor truck is constructed with 12# low alloy steel and 5mm,4mm,10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed .All the waste water can go directly into the sewage tank,so as not to corrode the body and the chassis.Morever,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.The garbage tank compacts the waste by a hydraulically powered mechanism,which employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall.
5. Equipped with two sets of hydraulic operation systems.Types of collect garbage: barrel collecting,bucket collecting,box collecting.
 Optional EquipmentWe can make the garbage compactor truck according to customer's requirements with the optional equipments below:
1. Rear turnover mechanism;
2. Back swing arm mechanism;
3. Hopper
4. Side compression with draw bar hoisting mechanism, rear hydraulic door, with compression function in dustbin.
5. Compressor
6. Please advise us in advance if you have any special requests for the garbage compactor truck, we can equip various kinds optional equipment for you.PurposesGarbage compactor truck is mainly used for the sanitation department of municipal and large-scale factories and mines.The truck can transport a variety of garbages and bulk building materials(such as:ash , sand , stone and soil), ore and coal in mines and coal mine.It is especially suitable for transport household garbage in residential area.Product advantage1. Collection way of garbage compactor truck is simple, can eliminate the second pollution, compression ratio high,large loading capacity,high automation operation, good economy, double insurance system, high efficiency.There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.By the user of hydraulics,the barrel is locked during the overturning process.which is very safe and realiable.
2. Best Quality with competitive price.



Relevant Products

1.Water Truck  2.Insulation Truck and Milk Truck 3.Sewage Suction Truck  4.Garbage Truck

5.Manlift Truck/Aerial Platform Truck  6.Truck with Crane 7.Fuel Truck/  8.Chemical Truck

9.Bulk Cement Truck  10.Concrete Mixer Truck  11.Fire Truck  12.Dump Truck

13.Van Truck/Refrigerated Truck, 14.Wrecker/Tow Truck, 15.Flatbed Truck/Low Bed

16.Tractor,   17.LPG Truck; 18.Trailers

Company Information

 1.     Xiagong Chusheng (Hubei) Special-purpose Vehicle Manufacturing Co., Ltd. is a famous and the biggest
        manufacturer with very professional experience in special automobile field for more than 15 years in China.
        We have more than 3000 workers, 400 technicians, and factory scale is more than 690,000m2.

2.     Our most advantage and leading products including LPG tanker series, Water Tank, Fuel tank, Refrigerated
       Truck, Garbage Truck, Towing/Wrecker truck, Dump Truck, Sewage Suction Truck, Concrete Mixer Truck,
       Bulk Cement Truck, Van Truck, Sweeper Truck, Truck with Crane, Fire fighting Truck, High-altitude Operation
       Truck, Chemical Liquid Truck, Milk Transport Truck, LED Display Truck, Various Semi-trailer, Spare parts etc.

3.     We have successfully exported to more than 60 countries, such as Ghana, Togo, Sudan, Kuwait, Peru,
       Nigeria, Benin, Angola, Tajikstan, Azerbaijan, Namibia, Burma, Korea, Iran, Afghanistan, Iraq, Philippines,
       Vietnam, Saudi Arabia, Mexico, Chile, Bolivia, Tanzania, Zambia, Zimbabwe, Yemen etc.

We have strict quality control of raw material, professional management team and technical workers, advanced
equipments, strict inspection before delivery, excellent packing and shipping team.
