DFAC 7cbm 6 Ton Road Sweeper Truck
Sinotruk Hubei Huawin Imp. & Exp. Co., Ltd.- Type:Sweep and Suck Type
- Certification:ISO9000, CCC, CE
- Transmission Type:Manual
- Emission Standard:Euro 3
- Fuel:Diesel
- Payload:6 Ton
Base Info
- Model NO.:DFL
- Use:Burnishing
- Cleaning Process:Cold Water Cleaning
- Condition:New
- Color:White or as Customers′ Option
- Driving Type:LHD,Rhd
- Cargo Material:Carbon Steel
- Engine Power:120 HP
- Cleaning Rate:>96%
- Transport Package:Nude
- Specification:ISO
- Trademark:DFAC
- Origin:China
- Production Capacity:800 Units,Month
Description
New condition/LHD&RHDChassis Curb weight(kg) 5705 Wheelbase(mm) 3800 Dimensions(mm) 6700×2290×2500 Overhang (front/rear) (mm) 1180/1715 Wheel track (front/rear) (mm) 1835/1640 Approach/Departure angle(°) 22/12 Axle Load(kg) 3460/5940 Max. driving speed(km/h) 90 Brand Dongfeng Model EQ Tire Number 6 Specifications 8.25-16,7.50-16,8.25R16,7.50R16 Clutch Reinforced diaphragm clutch Front passenger 2+1 Engine Model CY4102-C3C Displacement(ml) 3856 Power(kw) 88 Emission standard Euro 3 Brakes Service brake: dual circuit compressed air brake
Parking brake(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake Steering Gear Power steering, hydraulic steering with power assistance Equipment 1. Combine functions of sweeping, cleaning and watering, convenient to operate.
2. Sweep width: 3000 mm, cleaning speed: 5~15km/h.
3. Cleaning efficiency: 95%, maximum inhalation size: 120mm;
4. Nozzle minimum ground clearance: 200mm
5. Sweeping brush: 4, cleaning stainless steel tanks
6. Vacuum suction nozzle
7. Hydraulic control system. Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers
Main products
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
FAQ
1. MOQ: 1 unit
2. Optional payment terms: T/T or L/C
T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of T/T
Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 100000km, which comes the first.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.
Your are always welcome to visit our factory at any time.
