• Model NO.：CQ5254GJBHTG384
• Drive Mode：6x4
• Maximum Horsepower：200-300hp
• Condition：New
• Sizes and Details：for More Communications
• Certificate：3c, ISO,BV,GOST,SGS,GMP,
• Visit：Welcome
• Reputation：Reputation
• Engine：371HP
• Emission：Euro II
• Front Axle：Hf9
• Rear Axle：Hc16
• Tyre：12r22.5
• Overall Dimensions：9780mm*2496mm*3990mm
• Transport Package：Nude, RO-RO, Bulk Freigh
• Specification：3c, ISO, BV, GOST, SGS, GMP,
• Trademark：HOWO Brand
• Origin：People Republic of China
• HS Code：8705400000
• Production Capacity：50, 000 Units,Year.

mixer semi trailer


MAIN DESCRIPTION
Overall Dimensions
9780mm*2496mm*3990mm(L*W*H)
Tare Weight
13950kg
Payload
28000kg
Front Overhang
1500mm
Rear Overhang
2880mm
Wheelbase
4000mm+1400mm
Track (F/R)
2022mm/1830mm
CHASSIS
Chassis Brand
SINOTRUK HOWO
Chassis Model
ZZ1257N4048W, driving type 6x4
Cab
HW76, left hand drive, air-conditioner, one sleeper
Engine
SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L
Transmission
HW19710, No. of speeds: 10 forward  2 reverse
Steering
German ZF8098, turning system pressure 18MPa
Rear Axle
HC16 tandem axle, rated load 2x13ton, ratio 5.73
Wheels and tires
Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel
Brakes
Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake
MIXING SYSTEM
Mixing Volume
10cbm
Water Tank Volume
440L
Hydraulic Pump
Brand: ARK, Italy
Motor
Brand: ARK, Italy
