• Model NO.：GYV-7000
• Bearing Capacity：Medium
• Car Type：Bread Type
• Condition：New
• Name：Tank Truck
• Color：Silver
• Capacity：50000L
• Function：Multifunction
• Transport Package：Tank Truck Packing Box
• Specification：3*2*12
• Trademark：genyond
• Origin：Shanghai
• HS Code：8479899990
• Production Capacity：5000

Parameters for 5000 liters milk tanker truckChassisDrive Model4X2, right had driveCabD1695 single lineVehicle Main DimensionsDimensions(L x W x H)(mm)5875*1840*2210Wheel base (mm)3360Overhang (front/rear) (mm)1085/1430Wheel track (front/rear) (mm)1530 / 1425Approach/Departure angle(°)22 /21Weight in KGSLoading weight (kg)5250Displacement (ml)2771Emission standardEuro IIThickness(mm)Inner layer :3mm 304-2B stainless steel, Middle layer(thermal insulation): 80mm polyurethane foam insulation, Outside layer:2 mm 304-2B stainless steelStandard Configuration1,The tank is made up of three layers:outside layer(for physical protection),middle layer(thermal insulation),inner layer tank(for milk filling).Outside layer:2 mm 304-2B stainless steel3.The inner tank material is high quality food grade stainless steel304-2B,and it has been polished.4,Equipped with CIP self-cleaning devices, 10m wired hose. The ID of the wired hose is 51mm.
