• Fuel：Diesel
• Drive Wheel：4X2,6X4
• Brand：Isuzu
• Models：Small,Medium,Large
• Usage：Compression Type
• Condition：New
• Name：Isuzu Garbage Truck
• Engine：4kh1,4HK1,6HK1,6uz1,6wg1
• Transport Package：Naked
• Trademark：ISUZU
• Origin：China
• HS Code：8705400000
• Production Capacity：20000,Year

Specifications                            ISUZU VC46 GARBAGE TRUCK                          ModelQL1250UTCZY  Driving type: 6*4 left hand drivingEngineMake: ISUZU Diesel 4-stroke direct injection diesel engine, electronic controlEngine model:6UZ1-TCG40, Euro IV emission standard 6-cylinder in-line with water cooled, turbo-charging and intercoolerMaximum output: 350HP-380HP/257KW-279KWMaximum torque: 1450 NmDisplacement: 9.8 LTransmissionFAST 9JS150TA-B, 9 forwards and 1 reverse,manualRatio:12.65   8.38   6.22  4.57   3.40  2.46   1.83   1.34  1   13.22 (R) Front AxleISUZU F075, 7.5 Ton loading CapacityRear AxleISUZU RT210,21 Ton loading capacity,speed ratio 5.571ChassisFrame: U-profile parallel ladder frame and reinforced subframe with size 320×90×8 MMFront suspension:12 semi-elliptic leaf springRear suspension:12  semi-elliptic lea springAluminium fuel tank: 400 L capacity with locking fuel cap, fitted to the off side of the chassisSteeringPower steering,  hydraulic steering with power assitanceBrakesService brake: dual circuit compressed air brakeParking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheelsABS Wheels & TyresTire: 11 pcs 11.00-20Option:11.00R20, 295/80R22.5Driver's CabISUZU Flat roof cab, with two seats, 1 bed, A/C, electric glass, central lockElectricsOperating voltage: 24 V, negative grounded  Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W  Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse lightDimensions  mmWheel base4605+1300 MMOverall length9850 MMOverall width2500 MMOverall height 3500 MMWeight  kgDead weight14600 KGRated Loading Capacity13900 KGGross vehicle weight(GVW)28500 KGFront axle loading capacity7500  KGRear axle loading capacity21000 KGMax compression force (kg) >35000
