• Model NO.：ZZ1257N3841W
• Payload：40T
• Fuel：Diesel
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Color：Customized
• ABS：Optional
• AC：Optional
• Delivery：45 Work Days
• Transport Package：Nude Packing After Be Waxed
• Specification：standard size
• Trademark：SINOTRUK
• Origin：China
• HS Code：8705400000
• Production Capacity：5000pieces,Month

Ratio of Every GearTorque
(Nm)Rated Speed
(rpm)Weight
(kg)Oil Capacity
(L)1^st2^nd3^rd4^th5^th6^th7^th8^th9^th10^thR1R214.2810.627.875.874.383.262.431.81.341.0013.913.181900260036312Steering GearZF8118, German ZF hydraulic steering with power assistanceClutchSingle plate φ430 diaphragm spring clutchNumber of axle3Front axle HF9  STEYR/HOWO drum brake front axle, axle loading capacity is 9000kgDriving axleHC16    Rated loading capacity: 16T, Ratio: 4.42, 4.80/5.73
Double reduction, casting axle housing, drum brakeFront/Rear track(mm)2022/1830Overhang front/rear(mm)1500/2210Wheel base (mm)3825+1350Tires 12.00R20, radial tires, 10+1(spare tire)Approach/departure angle16/23 (°)Maximum speed(km/h)78Fuel Tank400LVan dimension10M³SuspensionSteer Axle: Parabolic springs with shock absorbers and stabilizer
Drive Axle: Parabolic springs with divided balance shaft and stabilizerElectrical SystemVoltage: 24V
Batteries: 2x12V 165Ah
Starter: 24V, 5.5KW
Alternator: 28V/80ABraking SystemService brake: Dual-circuit air brake
Parking brake: Spring brakes on rear axle
Auxiliary brake: Exhaust valve braking(EVB)ColorStandard: red, yellow, green, white, blue, black
Optional: others you likedOverall Dimension(L X W X H mm)9000×2496×4000othersWith PTO, Rear spare tire rackOptionsABS, Electrical tilting cab, MTCO tachographs
Our company also have pump trucks that works with the mixer trucks. If you need it, pls feel free to contact me


 Warranty
_{(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.}

Our strength:
_{1) Manufacturer, more than 14yrs professional experience.
2) CCC,SGS and ISO9001 certificate, one year guarantee term provided.
3) Small order can be accepted.
4) Products can be custom-made according to your design, or diversified needs.}
