• Model NO.：CLW
• Drive Wheel：4x2
• Hoesrpower：150-250hp
• Condition：New
• Product Name：Dongfeng 4X2 5cbm 90HP Vacuum Sewage Suction Truck
• Drive Mode：4X2
• Chassis Brand：Dongfeng
• Drive Type：LHD,Rhd
• Tire：9.00-20, 8.25-20
• Color：White, Yellow, Blue or Customized
• Engine Brand：Cummins, Yuchai Brand
• Horse Power：90HP, 120HP, 160HP, 180HP
• Pump of Sewage Tanker Truck：Italy Brand High Pressure
• Wheel Base：4500mm
• Transport Package：Waxed Before on Board
• Specification：ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
• Trademark：CLW BRAND
• Origin：Hubei Suizhou
• Production Capacity：500sets,Month

Products Name
Fecal Suction Truck
Tank Capacity(m3)
3.5
Gross Vehicle Weight(Kg)
6495
Rated Payload(Kg)
3300
Curb Weight(Kg)
3195
Overall Dimension(mm)
5850 ×1960 ×2 55 0
Cab Allowed Persons
3
Dive Type
4x2
App/Dep Angle(°)
19 / 13
F/R Suspension(mm)
1 032 / 1663
Alex No.
2
Wheelbase(mm)
33 00
Alex Load(Kg)
203 0/ 2465
Max Speed(Km/h)
90
Others
1. Transport Material: Manure mixture, density is about 900Kg/ m3,effective capacity is about 5 m3.Tank overall dimension(mm):Length is 300 0mm,long axle is 110 0mm,short axle is 70 0mm

2. Equipped with PTO, Vacuum Pump, Ladder, Pipe System,etc.
[ Chassis Technical Parameters ]
Chassis Model
EQ1060TJ20D3
Chassis Brand
DONGFENG
Overall Dimension(mm)
5850 × 1960 ×2 550
Tyre No.
6
App/Dep Angle(°)
19/15
Tyre Specification
6.50-16
Spring Leaf No.
8 / 9 + 5
Front Track(mm)
1 506
Fuel Type
Diesel
Rear Track(mm)
1 442
Emission Standard
EURO II
Engine Model
YC4F90-30
Engine Brand
Yu Chai
Power
90hp/66kw
Displacement(ml)
2659


About us

We CLW Heavy Industry Co., Ltd. are a professional manufacturer and exporter which is concerned with the design, development and production of more than 300 kinds of trucks, semi-trailers, and storage tanks.
All of our products comply can reach the international quality standards and are greatly appreciated in a variety of markets around the world.

 1. CLW Heavy Industry Co., Ltd, which was appointed by the Development and Reform Committee of China, is a famous manufacturer producing all kinds of special trucks for municipal & environmental construction, petrol & medicals, container, and semi-trailer. Nearly 15 years wholesaler experience in producing truck.

  2.Our company has independent export right and has amount of clients overseas including Africa, North America, Middle East, Australia and so on. The export turnover has reached 25million dollars.

 3.Our company has good after-sales service, solid technology, flawless inspection for our dear customers.


Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )






Packaging & Shipping:
1. Naked or waxed before on board.
2. Delivery time: 30 days after receiving payment in advance.
3. By RORO or Bulk ship.



Our warranty:
1. One year quality guarantee for three key parts: Axles, engine, transmission.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.


FAQ
1. Q: How about the quality of trucks of your factory?
   A:  Our trucks get ISO 9001:2008 and CCC, B&V and other related certificates. The chassis and spare parts   come from the original manufacturers with anti-fake label.
2. Q:How many years of your company's service, especially after-sale service?
  A: CLW Heavy Industry Co., Ltd has been in this field for nearly 15 years and has strong production and distribution capability, we can produce your products in 15 working days. We offer 1 year after-sale service.
3. Q:Is there any advantages of your price?
   A: CLW Heavy Industry Co., Ltd is one of the most important suppliers of Sinotruk, Shacman, Dongfeng, FOTON and FAW, which provides guarantees for reasonable price and good quality.
4. Price term: FOB, CIF.
5. Payment: 30% deposit after order confirmation, 70% balance should be paid before delivery. All are by T/T, L/C.
6. Delivery time: 25 working days after payment is received.
7. Standard Steering: Left-hand drive, if you need Right-hand drives, please inform  us, will make special  order for you.


Any question please contact me without hesitation!!!
