• Model NO.：3m3
• Drive Mode：4x2
• Maximum Horsepower：<200hp
• Condition：New
• Chassis：Dongfeng,Foton
• Mixer Volume：3cbm,4cbm
• Blades：Wear Resistant
• Hydraulic Driving System：Imported
• Concrete Truck Mixer Control：Three-Point Control
• Water Supply：450L Tank with Reinforced Pipe
• Drum Process：Shot Blasting Pretreatment
• Concrete Truck Mixer Welding：Spot Welding
• Coating&Painting：Bus Baking Varnish Standard
• Radiator：Emergency Switch Installed
• Transport Package：Standard Packing for International Transport
• Specification：ISO CE certified
• Trademark：FOCUS
• Origin：Henan Zhengzhou
• HS Code：8705400000
• Production Capacity：60set Per Month

[ Main Technical Parameter ]Chassis BrandFOTONBatch No.256Product NameBJ5145GJB-1 Concrete Mixer TruckTruck ModelZK3WU4C8044Total weight(Kg)13570Tank Volume(m3)3.30Rated Load(Kg)7395Dimension(mm)6460x2255x3300Curb Weight(Kg)5980Passenger(person)3Approach angle/departure angle(°)24/20Front overhang/rear overhang(mm)1230/1830Axel No.2Wheelbase(mm)3400axle load (Kg)4860Max. Speed(Km/h)83OtherMixing Volume:3m3
Material of side and below protective device:Q235 steel,
Connection type: Bolt Connection
Height of back protective device:500mm[ Chassis Parameter ]Chassis ModelBJ1145VJPFA-1BrandFOTONDimension(mm)6070x2180x2510Quantity of Tire6Approach angle/departure angle(°)24/22Tire specification8.25-20Steel Spring No.10/12+9Front Tread(mm)1774FuelDieselBack Tread(mm)1669EMISSION STANDARDEuro IIIEngine ModelEngine ManufacturerDisplacement(ml)Power(Kw)YC4D130-41Guangxi YuChai Diesel Engine Co., Ltd420096
