• Drive Wheel：6x4
• Hoesrpower：350-450HP
• Condition：New
• High Pressure Cleaning Vehicle：1
• Transport Package：Nude
• Specification：8-16 M3
• Trademark：HINO
• Origin：China
• HS Code：8701909000
• Production Capacity：5000 Per Year

Model

ZZ3257N3867W

 Driving type: 6*4 right hand drivingEngineMake: SINOTRUK Diesel 4-stroke electric control conmon rail Engine model: WD615.96C, Euro 3 emission standard  6-cylinder in-line with air cooling, turbo-charging and intercooling  Maximum output: 380 hp(279kw) at 2000 rpm Maximum torque: 1590N.m at 1200-1500r/min Number of cylinder: 6 Displacement: 9.726 L TransmissionHW19710, 10 forwards and 2 reverse Ratio: 14.28 10.62 7.87 5.87 4.375 3.26 2.43 1.8 1.34 1 13.91(R1) 3.18(R2) Front AxleHF9, Steering with double T-cross section beam,drum brake Rear AxleHC16,pressed axle housing,  central single reduction with hub reduction Loading Capacity Rear Axle (Kg.) 2*16000 kgs, Standard Ratio:5.73       ChassisFrame:  U-profile parallel ladder frame with section of 300X80X8mmFront suspension:10 semi-elliptic leaf springRear suspension:12 leaf semi-elliptic springsAluminium Alloy fuel tank: 300L capacity with locking fuel cap, fitted to the off side of the chassis Wheels & TyresTire: 12.00R20, radial tyre Driver's CabHW76 cabin, 2 seats+1 bed  ElectricsOperating voltage: 24 V, negative grounded  Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W  Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light Dimensions  mm  Overall length8200Overall width2496Overall height 3500Dimension of the rear dump body Compactor Body
 Volume of body(m3)  20Volume of filler(m3)2.5Time of one filling cycle(s) ≤25Lifting time of filler (s)   8-10Time of discharge (s)     ≤40Pressure of fluid system (Mpa)    20Front/rear sewage capacity (L) 250+150Max compression force (kg) >35000Main Exporting Products

Heavy-duty Trucks:
Tractor Truck, Cargo Truck, Mining Dump Truck, Dump Truck, Concrete Mixing Truck, Water Spray Truck, Sewage Suction truck, Oil Tank Truck, Barbage Truck, Fire Rescue Truck, Semi Trailer

Light-duty Trucks:
Cargo Truck, Box Truck, Special Using Truck

Construction Machinery:
Truck Crane, Wheel Loader, Road Roller, Excavator, Motor Grader, Paver, Tower Crane, Asphalt Mixing Plant & Concrete Mixer, Scissor Type Hydraulic Lift Platform, Aluminum Alloy Hydraulic Platformhigh-pressure hose Length      m50
