Sinotruk HOWO 5cbm Foam Fire Truck 5000 Liters Water Fire Fighting Truck
Hubei Fuya Vehicle Co., Ltd.- After-sales Service:Supply After Service
- Warranty:1 Year or 30000km
- Type:Rescue
- Certification:ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
- Volume:7001-10000L
- Emission Standard:Euro 2
Base Info
- Model NO.:CLW4FE2
- Transmission Type:Manual
- Payload:10t
- Fuel:Diesel
- Drive Wheel:4×2
- Horsepower:150-250hp
- Condition:New
- Description:HOWO off -Road Fire Truc
- Filling Type:Water Tank Fire Truck, Water Tanker Fire Truc
- Ank Volume:4cbm, 4000L, 4000liters, 5cbm 5000L 6cbm
- Max Fire Monitor Range:40~45m
- Driving Model:4*2 6*4 8*4 LHD Rhd
- Atmospheric Pressure Pump:BS30
- Powder Tank Capacity:1cbm,2cbm,3cbm
- Destination Country:Fire Truck for Dubai, Afghanis
- Cab:Flat Head,Double Row Seat,Four Door
- Rated Flow:20~40L,S
- Transport Package:Waxed Before on Board
- Specification:ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
- Trademark:CLW
- Origin:Hubei Suizhou
- HS Code:87053010
- Production Capacity:500unit,Month
Description
HOWO Foam-water Combined Fire Truck8 tonsChassis Model howo 4x2 chassis Weight Parameter (kg) Load weight 10000 Overall Dimensions(mm) 8950×2500×3510 Curb weight 12050 Box Dimensions(mm) / MAX overall weight 22050 Wheelbase (mm) 4600 Engine Model WD615.92E Type / Power/ Displacement(kw/ml) 196/9726 Product factory Sino-Truck Co.,Ltd Performanceparameter Max speed (km/h) 90 Track Span (mm) Front axle 20,222,041 Max creeping slope capacity (%) 34 Rear axle 1830 Oil consumption/100K(L) 30 Reaching out of vehicle (mm) Front overhang 1500 Slope stop for empty vehicle (%) 20 Rear overhang 2650 Min circle turning Diameter(m) 15.6 Driving angle (°) Proximal angle 26 Smallest ground clearance (mm) 255 Off angle 13 Gearbox Machine type 6-speed transmission Tire 10.00-20-16PR Cab Flat head all metal to up.Five passenger allowed Tank effective volume 8(m³) SpecialFunction Water tank volume(L) 6000 Foam tank volume(L) 2000 Fire Monitor Model:PS50 Water monitor rated pressure:0.5-1.2MPa
Water monitor rated flow:50L/S Water monitor rated reach≥70m Pitching angle(°):-30~70 Level back to the corner(°):360 Spray angle(°)≥100 Fire Pump Model:CB10/60 (1)pump pressure (Mpa):1.0
flow(L/S):60L/S/1.0MParotate speed(rmp):2800power(kw)98.5
time of drawing water:40s (2)pump pressure (Mpa):1.3
flow(L/S):42L/S/1.3MParotate speed(rmp):2990power(kw)93.5
time of drawing water:40s
Exporting
1.58 sets of military water trucks for national defense
2. Dump trucks in support of the United Nations
3. Fuel tank trucks exported to Sudan
4.78 sets of water truck exported to Nigeria
5. Dump trucks exported to the Ivory Coast, Kazakhstan
6.108sets of trucks exported to Libya
7.36 sets of dump trucks exported to North America
8.218 sets of garbage trucks exported to West Africa
9.60sets of water trucks exported to Congo
10. Garbage trucks exported to Vietnam
11.98 sets of dump trucks exported to Ghana
If you are interested in our trucks, pls contact me, I will send our best quotation to you!
we sincerely welcome you to visit our factory and provide your precious suggestion for us!
