• Model NO.：Concrete Pump Truck
• Specification：ISO
• Trademark：SINOTRUK
• Origin：China
• HS Code：84134000
• Production Capacity：3000pieces,Month

Basic Info.

Model NO. Concrete Pump Truck Specification ISO Trademark SINOTRUK Origin China HS Code 84134000 Production Capacity 3000pieces/Month

Product Description

 Your are always welcome to visit our factory at any time.

Our main Overseas Business Scope:
- All types of heavy duty truck
- Special modified vehicle
- All types of semitrailer
- Construction equipment&Machinery
- Pickup, VAN, Bus
- Spare parts- Service & Maintenance
Our complete selling system including sale, spare parts sale, after-sale service and customer service.

1.Basic technical data:

Pumping system	(/)Max. Theor. output(high/low pressure)	m3/h	55/80
	(/) Max. Theor. concrete output Pressure(high/low pressure)	MPa	13/7.5
	Rated working pressure	MPa	32
	(/) Pumping frequency(high/low pressure)	min-1	18/30
	Hopper capacity	L	450
	Filling height	mm	1450
	Hydraulic system type		Open loop
	Distribution valve		S S valve
	×    Oil cylinder dia.×stroke	mm	φ100×1650/1400
	×Concrete cylinder dia.×stroke	mm	φ200×1650/1400
	Hydraulic oil cooling		Air cooling
	Recommended concrete slump	cm	12~23
	Max. aggregate dimension	mm	40
Placing boom	Structure type		33-4M
	Placing depth	m	33
	Horizontal distance	m	33
	Placing depth	m	22.4
	Slewing angle		365°
	Pipe diameter	mm	125
	End hose length	mm	3000
	Min. height of opening placing boom	mm	11900
	(××)Outriggers span (front×rear×side)	mm	6140×7098×6706
Chassis and the whole machine	Chassis model		ZZ5207N5617D1
	Wheelbase	mm	5600
	Engine type		D10.34-40
	Engine power	kW	249kw
	Oil tank cubage	L	400
	Tail gas exhaust standard		IV
	(××) Overall dimensions	mm	10750x2480x3648

 Our Factory
  SINOTRUK has an annual output of 180,000 vehicles and 200,000 engines capacity.
Your are always welcome to visit our factory at any time








Packing,Delivery,Main products




Our Advantages
(1)Competitive Factory Price and Excellent Quality
(2)More than 20 years' experience as a manufacturer
(3)Products Quality Certification SGS CCC ISO
(4)Perfect after-sale service
(5)Customized products available with us
(6)Export to more than 90 countries and regions

 FAQ


Q1: I don't want this configuration

A: The configuration can be changed according to your needs

Q2: Minimum order quantity?

A: MOQ is 1 unit.

Q3:  Production period?

A: (Truck & trailer) Within 30 days since the moment we got your down payment       (Parts)  Within 7 days since the moment we got your down payment

Q4: Payment term?

A: (Truck & trailer)  30% T/T as deposit, the balance should be paid before delivery. or L/C       (Parts)  100% T/T should be paid before delivery

Q5: Shipping?

A: (Truck & trailer)       by container or RoRo/Bulk shipment. (South America, Middle East, Africa, Oceania etc.)       by road or railway.(Russia, Mongolia, Kazakhstan, Uzbekistan , Vietnam, Laos etc.)       (Parts)       by international courier service, such as DHL, TNT, UPS, or Fedex. The goods above $1000 can be shipped by sea

Q6: Can you supply some quick-wear truck or semi trailer parts ?

A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan, bearings etc.



6. Warranty
(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.


 Company information
China Heavy Duty Truck Import&Export Co.,Ltd is one of the main exporters of Chinese trucks which is authorized by Ministry of Commerce
Staff of our company can provide the trucks meeting the requirement of customers at the best price. We have many years of experience in exporting trucks. If you want to buy any truck, trailer or truck parts,please contact us!
We sincerely hope to cooperate with you to expand market in your country!

China Truck International Ltd is one of the main exporters of Chinese trucks which is authorized by Ministry of Commerce.
Staff of our company can provide the trucks meeting the requirement of customers at the best price. We have many years of experience in exporting trucks.
If you want to buy any truck, trailer or truck parts,please contact us!
We sincerely hope to cooperate with you to expand market in your country!


Contact person: Nancy
Tel:+8618562608309
