• Drive Wheel：4x2
• Hoesrpower：160HP
• Condition：New
• Fuel Type：Diesel
• Drive Model：Right Hand Drive & Left Hand Drive Sewer Vacuum Tr
• Gearbox：10 Forwards & 2 Reverse
• Tank Material：6mm Carbon Steel
• Vacuum Pump：Chinese Brand or B, Jurop, Keiser Moro
• Sewage Suction Pipe：7m
• Suction Time：<5min
• Effective Suction Range：>8m
• Painting：Customized
• Delivery Time：30 Days
• Certificate：ISO CCC SGS BV
• Warranty：1 Year
• Tanker Volume：8m3, 10m3, 12m3
• Chassis Brand：HOWO, Dongfeng, Isuzu, Foton, JAC, etc.
• Tire：6tires with One Spare
• Transport Package：Naked, RO-RO, Bulk
• Specification：6800*2300*2850mm
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：87059099
• Production Capacity：500 Units,Month

ItemsDescriptionsSpecifications and TypesGeneralTruck NameSewage suction truckDrive Type4*2Gross Vehicle Weight(kg)7360Curb Weight (kg)3590Curb Weight (kg)3640Overall Dimensions L*W*H(mm)6200*2300*2800 Engine BrandQuanchaiFuel TypeDieselPower156HPEmission StandardEuro 2/ 3/ 4/ 5Displacement(ml)3856Engine Type4 cylinders in line,water cooling, turbo-charged diesel engine,inter-coolingChassisChassis BrandDongfengFront/Rear Axle Load(KG)2500/5000Tire No.6Tire Specification7.00-16/ 7.50R16Wheelbase (mm)3800Axle No.2Gear Box6 speed forward with 1 reverse, manualSteering WheelLeft / Right hand drive with power-assistedBrakeOil brakeRadiatorSuitable for tropical climateSucking SystemSewage tank Volume(L)5000Tank shapeRoundTank Material5mm thick carbon steelSuction Depth(m)More than 6 meterSuction hose length8 metersTank Tipping angle(°)More than 45Rear doorOpen and closed by hydraulic cylinders

Structure of Vacuum septic truck

Working Diagram:






The CLW group, which was appointed by the Development and Reform Committee of China. CLW group is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.

Main Products :

1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
