• Model NO.：CLW
• Fuel：Diesel
• Drive Wheel：4×2
• Horsepower：＜150hp
• Condition：New
• Description：4*2 Dongfeng Fire Fighting Trucks
• Filling Type：Water Tank Fire Truck, Water Tanker Fire Truc
• Ank Volume：4cbm, 4000L, 4000liters, 5cbm 5000L 6cbm
• Max Fire Monitor Range：40~45m
• Driving Model：4*2 6*4 8*4 LHD Rhd
• Atmospheric Pressure Pump：BS30
• Powder Tank Capacity：1cbm,2cbm,3cbm
• Destination Country：Fire Truck for Dubai, Afghanis
• Cab：Flat Head,Double Row Seat,Four Door
• Rated Flow：20~40L,S
• Transport Package：Waxed Before on Board
• Specification：ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
• Trademark：CLW BRAND
• Origin：Hubei Suizhou
• HS Code：87053010
• Production Capacity：50 Unit,Month

DescriptionDF XiaoBaWang Water-Foam  Fire Fighting TruckDrive Model4X2ChassisEQ1042CapacityWater tank:1500L
Foam tank:500LVehicle Main DimensionsDimensions(L x W x H)(mm)6310X1980X2400Water tank dimensions1000x1700x1000Foam tank dimensions500x1700x700Wheel base (mm)3300Overhang (front/rear) (mm)1032/1853Wheel track (front/rear) (mm)1508/1458Approach/Departure angle(°)23/15Weight in KGSGVW.4495Curb Weight2705Max. driving speed(km/h)90EngineModelCY4102Type4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)95 HPengine capacity(ml)3707Emission standardEuro IIIGearbox5 forwards & 1 reverseClutchReinforced diaphragm clutchSteering GearPower steering, hydraulic steering with power assistanceFuel tank (L)120Tire7.00-15tire , 6 + 1(spare)Brakesdual circuit compressed air brakeCabfour doors, double row EquipmentWater tanker: 1500L  Foam Tanker:500L
Middle and low pressure pump :CB20.10/15.30H
Flow:middle pressure 15L/S   low pressure 30L/S
Pressure: middle pressure 2.0MPa  low pressure 1.0MPa
PL30 Fire Pump  Flow: 30L/S
Pressure: 1.0~1.2MPa
Fire distance (water):≥45m



If you are interested in our trucks, pls contact me, I will send our best quotation to you!
