• Use：Stainless Steel
• Cleaning Process：Cold Water Cleaning
• Condition：New
• Gear Box：5 Forwards & 1 Reverse
• Garbage Box Volume：2m3, 4m3, 5m3, 6m3, 8m3
• Sweeping Width：2.8m
• Suction Rate：96%
• Sweeper Rotation Speed：80 R,Min
• Cleaning Capacity：40000m2,H
• Color：Customized
• Warranty：1 Year
• Delivery Time：30 Days
• Transport Package：Container, RO-RO, Bulk
• Specification：6200*2000*2590mm
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：87059099
• Production Capacity：500units,Month

Product model and nameCLW5070GQXE5Gross weight(Kg)7360Drive type4X2Payload(Kg)2250Overall dimension(mm)5980×2200×2600Curb weight(Kg)4980Cab seats2Approach/departure angle(°)20/13Front/rear hang(mm)1040/1632Axle No.2Wheelbase(mm)3308Axle load(Kg) 2640/4720Max speed(Km/h)99Tank volume(m³)3m3Tank material304 stainless steelChassis specificationChassis modelEQ1070SJ3BDFManufacturerDongfeng Motor Co.,LtdBrand nameDONGFENGFuel typeDIESELTyre specification 7.00-16Tyre No.6Rear track base(mm)1494Front track base(mm)1503Emission standardEURO 3Transmission5 forward gearsCabWith Air conditioning and power steering.Engine modelEngine manufacturerDisplacement(ml)Power(Kw)CY4BK551Dongfeng Chaoyang Chaochai Engine Co.,Ltd370775Feature and Application1.Use Automatic control system,electric/gas system,hydraulic system central contril,easy operation, all can be operated in cabin by driver2.clean device in the front of left side,both side can clean, 4 sets of rolling brush tight the guard bar and rolling to clean, washed by high pressure water,electric hydraulic type is used for isolation barrier; Use hydraulic telescopic boom to clean, main boom can lift up and down, brush boom can telescopic front and back to guarantee the clean efficiency.3.Water tank material is 304 Stainless Steel, High strength corrosion and rust prevention, Improve safety in urban areas4.The water tank is equipped with a low-water sensing alarm device
Woking Photos







Company Introduction



Overseas Exhibition and Local Support



Customer  Visiting and inspection



Cargo Shipping Methods
