Specialized Vehicle

Home > Product > Garbage Truck

Sinotruck HOWO Used New Garbage Compactor Truck

QINGTE GROUP SPECIAL VEHICLES CO., LIMITED
  • Type：Compactor
  • Certification：ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
  • Volume：3001-6000L
  • Emission Standard：Euro 2
  • Transmission Type：Manual
  • Payload：20T

Base Info

  • Model NO.：ZZ1257M4647
  • Fuel：Diesel
  • Drive Wheel：6×4
  • Brand：HOWO
  • Models：Micro
  • Usage：Dump, Swing Arm Type, Sealed, Hang Barrel Type, Arm Type, Compression Type, Eat Hutch Type
  • Condition：New
  • Delivery Detail：Within 10 Days After Receive Your Payment
  • Color：Optional
  • ABS：Optional
  • AC：Optional
  • Transport Package：Carton Case or Under Client′s Requirement.
  • Specification：standard size
  • Trademark：SINOTRUK
  • Origin：China
  • HS Code：8716391000
  • Production Capacity：5000PCS,Month

Description


Total weight
25000kgs
Whole truck dimension
9800x2496x3048mm
Rated capacity
13870kgs
Garbage box dimension
7100x2326x2050mm
Kerb weight
11000kgs
Garbage box volume
16 m3 (16000L)
Passengers
2 people
Fillter volume
2m3
Approach/departure angle
16/15
Front/rear overhang
1500/2625mm
Axle no.
3
Wheel base
4325+1350mm
Pressure of Hydraulic System
20Mpa
Cycle Time of Filling
≤25s
Lifting Time of Filler
8~10s
Time of Discharging
≤40s
Max.Compression Force
>25000kgs

Front / rear sewage tank volume
250+150L
Chassis Parameters
Chassis brand
Sinotruck
Tyre nos.
10
Chassis dimension
9800x2496x1050mm
Tyre model
11.00-20 , bias tyres
Front axle
HF7 (7t)
Rear axle
HW1697 (speed ratio:3.93)
Steering
ZF8098 hydraulic steering with power assistance
(18MPa steering oil pump)
Transmission
HW15710 , 10 forward and 2 reverse (manual)
Fuel type
Diesel
Fuel tank
300L
Engine model
Emission standard
Engine power
Max. speed

WD615.87

EuroII


290hp


90km/h


Others of engine
1. Bore x stroke : 126x130mm
2. Displacement : 9.726L
3. Rated power & revolving speed : 266hp & 2200r/min.
4. Max. Torque & revolving speed : 1100N.m & 1100-1600r/min.Sinotruck HOWO Used New Garbage Compactor Truck
Sinotruck HOWO Used New Garbage Compactor Truck
Sinotruck HOWO Used New Garbage Compactor Truck
Our Factory:
Overall testing guarantees every vehicle is a competitive product. Sinotruk owns
professional road testing grounds for heavy trucks, so every new developed product
will be tested by extremely strict professional experiments during development
process.
Sinotruck HOWO Used New Garbage Compactor Truck

Packing:
Sinotruck HOWO Used New Garbage Compactor Truck


FAQ
Q1: I want the front two tires are bias tires and the rear 9 tires are radial tires, is it ok ?
   A: We can make the tires as your requirement to suit your country's need.
Q2: What about your products quality ?
   A: Quality is our culture! "Our factory has advanced production technology and management team!
   We always attach great importance to quality controlling from the very beginning!
Q 3: Can i have samples of this type of flatbed semi trailer to test the quality ?
   A: Yes, you can buy any samples to test the quality,our MOQ is 1 unit.
Q 4: What others we can do ?
   A: According to your order, we will provide the best price and quality trucks and trailers.
   And we are well capable in offering overseas after-sales service. Besides, we also provide rational
   packing and shipping program,let shipment save money and security.
Q 5: How to guarantee customers get the goods smoothly after they pay ?
   A: Don't worry, dear. We have been in this field for 10 years, we will send you production photos once in a while, and we will help you to book the latest ship.
Q 6: What's the delivery time ?
   A: The delivery time is within 15 working days after receiving your advance payment.
Q 7: Can you supply some quick-wear truck or semi trailer parts ?
   A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance   beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads,   brake pan, bearings etc.
 Q 8:  Do you have any used truck and semi trailer for sale ?
   A: We have some trucks and trailers in stock for choice, from 2010-2016 year, the price are favorable. We'll
   show you our stock if you need.
   Q 9:  Which INCOTERMS 2010 TERMS can we work ?
   MAOWO is a professional and sophisticated international player, can handle all INCOTERMS
   2010 terms, and we normally work on FOB, CFR, CIF, CIP, EXW.
   Q 10:  What logistics ways we can work for shipment?
   A: We can ship construction machinery by various transportation tools.
   (1) For 80% of our shipment, we will go by sea, to all main continents such as South America,
   Middle East, Africa, Oceania etc. Either by container or RoRo/Bulk shipment.
   (2) For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan , Vietnam, Laos  etc.,we can ship construction machinery by road or railway.
   (3) For light spare parts in urgent demand, we can ship it by international courier service, such as
   DHL, TNT, UPS, or Fedex.

Company information
China Truck International Ltd is one of the main exporters of Chinese trucks
which is authorized by Ministry of Commerce.
We have 20 years of experience in exporting trucks.
If you want to buy any truck, trailer or truck parts, please contact us!
We sincerely hope to cooperate with you to expand market in your country!
