• Model NO.：CLW
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Transport Package：Naked or Waxed
• Specification：CCC, ISO9001, SGS
• Trademark：CLW
• Origin：China
• HS Code：8705400000
• Production Capacity：500unit,Month

DescriptionDongFeng Concrete mixer truckDrive Model6X4
 Vehicle Main DimensionsDimensions(L x W x H)mm9017×2500×3970Wheel base (mm)3800+1350Overhang (front/rear) (mm)1500/2520Wheel track (front/rear) (mm)2027/1850/1850Approach/Departure angle(°)30/12Weight in KGSCurb Weight14050GVW.25000Max. driving speed(km/h)75
 EngineModelISLe340 30Type4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)340HPEmission standardEuro IIIGearbox10 forwards & 1 reverseClutchReinforced diaphragm clutchSteering GearPower steering, hydraulic steering with power assistanceFuel typeDieselTire12.00R20 Radial tire , 11 pieces including one spare tireBrakesService brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
 Mixer drumCapacity (m³)8-10Thickness16mmWater Supply PatternsAir PressureTilt(°)11°-13°Rotation Speed(r/m)0-18Material Discharging Speed3(M3/min)Material Remaining Ratio≤0.6%

Company information

Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special truck and trailer as well as other special equipment.Our company has independent export potence,and has a mount of clients overseas.

Our main products
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )


FAQ

Payment:
30% deposit by T/T after order confirmation, 70% balance should be paid before delivery by T/T or L/C.Other type of payment can be discussed.

Packaging & Shipping:

1. Naked or waxed before on board.
2. Delivery time: 30 days after receiving deposit.
3. By RORO or Bulk ship.

Delivery time:
25 working days after payment is received.


Our warranty:
1. One year quality guarantee for three key parts: Axles, engine, transmission.
2. Other spare parts could be supplied by OEM at cost prices.
3.Our engineers are always ready to deal with technical problem.

Ms. Janie Chen
Sales Representative

Chengli Special Automobile Co., Ltd
Factory: Chengli Automobile Industry Park,Suizhou, Hubei, China
Office: Block 2, Fengzeyuan Villa, Dongxihu District, Wuhan City, Hubei Province, China.
Mobile: +86-18771991406

Tel&Fax: +86-27-83796298
Web: https://chenglitruck.en.made-in-china.com
Customized LPG, Truck & Trailer Solutions to Meet Your Requirements
