• Model NO.：CLW5JBC45
• Drive Mode：4X2,6X4,8X4
• Maximum Horsepower：<200hp
• Condition：New
• Other Brand：Sinotruk Faw Shackman Beiben
• Weight：7490kg
• Dimension(L*W*H)：6850*2490*3180 Mm
• Engine Model：Yc4e140-20, 140HP
• Pump：Imported Brand, or Chinese Famous Brand
• Motor：Imported Brand, or Chinese Famous Brand
• Reducer：Imported Brand, or Chinese Famous Brand
• Driving Type：LHD or Rhd
• Brand Name：Dongfeng Concrete Mixer Truck, Cement Mixer Truck
• Mixer Truck Volume：3cbm, 4bm, 5cbm 8cbm Concrete Mixer Truck
• Transport Package：Waxed Before Shipment
• Specification：CCC, ISO
• Trademark：Dongfeng-CLW
• Origin：Hubei Suizhou
• HS Code：8701909000
• Production Capacity：1300unit,Month

Vehicle model
EQ5250GJBF
Manufacturer
Dongfeng Motor Company
Overall dimension
8700x2500x3760mm
Max gross weight
24900kg
Cement mix tank volume
8CBM
Rated load weight
11805kg
Approach/Departure angle
34/15
Curb weight
12900kg
Front/Rear suspension
1250/2300mm
Max. speed
85km/h
VIN
LGHXLJ4Pxxxxxxxxx
LGHXLJ4Rxxxxxxxxx
Chassis model
EQ1250GFJ3
Manufacturer
Dongfeng Motor Company
Engine model
Engine manufacturer
Displacement
Max. power
YC6A260-33
Guangxi Yulin Diesel Engine Co., Ltd
7255ml
191kw
Fuel type
Diesel
Emission level
Euro 3(EGR)
Transmission type
6x4 LHD
Tire number
10+1
Wheelbase
3850+1300mm
Tire size
10.00-20
Axle load weight
7000/17900kgx2(double rear axle)
Front wheel track
1980mm
Spring leaf tablet
9/10
Rear wheel track
1860/1860mm

Main parts parameterSpecial Fuction Description of Cement Mixer Truckhydraulic systemadopting equipment imported from Italy,Germany,Japan, layout of system is simple,reliable transportation.water supply systemusing pressure water supply type, simplifying structure, saving power, reducing the weight of entire vehicle.mixing drumadopting plow structure, double helical surface blades, using different blade in different conic part, improved the quality of concrete, tank body with small angle of inclination in installing, reducing the height of center of gravity of the entire vehicle, good driving stability, moreover, smaller angle of inclination is more favorable for dry concrete discharge, reducing residual ratio.operation equipmentincluding flexible manipulator and connecting rod type manipulator, connecting rod type manipulator can realize multipoint manipulation.feeding/discharging devicefeed hopper, discharge chute can be rotated 180 degrees in the horizontal direction, so that it can adapt to different discharge position.tank body spray-painttank body surface sprays two-layer polyurethane paint, using stoving varnish technology, uniform coating, strong adhesion, luster is more durable.


BEST COMPETITIVE PRICE WITH TRUSTED QUALITY

Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special truck and trailer as well as other special equipment.
LPG tank is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.

Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
More information of our cement mixing truck/concrete truck mixer, please feel free to contact with Ms. Helen Jiang. We will customize the truck according to your requirement.

Contact way::
Sales representative: Wendy Cheng
phone number: (+86) 13697357315
