• Model NO.：CLW545XWC
• Hoesrpower：150-250hp
• Condition：New
• Sewage Vacuum Trucks Brand：Dongfeng
• Sewage Vacuum Trucks Color：White, Yellow, Blue... as You Like
• Horse Power：90HP, 120HP, 160HP
• Sewage Vacuum Trucks Exhaust：4500ml
• Tire No：6
• Rating Rotate Speed：1400r,M
• Max Speed：90km,H
• Sewage Vacuum Trucks Production Cycle：6-7 Days
• Warranty：One Year for Two Key Parts (Engine, Gear-Box)
• Tyre Specification：6.50-16
• Transport Package：Naked and Waxed Before on Board
• Specification：CE, ISO9001
• Trademark：CLW
• Origin：Suizhou, Hubei
• HS Code：8705909990
• Production Capacity：10000 PCS Per Year

Main Technical Parameters  for  dongfeng 4x2 sewer septic truck ,  vacuum suction sewage truck
Products Name
Fecal Suction Truck
Tank Capacity(m3)
3.5
Gross Vehicle Weight(Kg)
6495
Rated Payload(Kg)
3300
Curb Weight(Kg)
3195
Overall Dimension(mm)
5850 ×1960 ×2 55 0
Cab Allowed Persons
3
Dive Type
4x2
App/Dep Angle(°)
19 / 13
F/R Suspension(mm)
1 032 / 1663
Alex No.
2
Wheelbase(mm)
33 00
Alex Load(Kg)
203 0/ 2465
Max Speed(Km/h)
90
Others
1.  Transport Material:   Manure mixture, density is about 900Kg/ m3,effective capacity is about  5 m3.Tank overall dimension(mm):Length is  300 0mm,long axle is  110 0mm,short axle is  70 0mm

2.  Equipped with PTO, Vacuum Pump, Ladder, Pipe System,etc.
[ Chassis Technical Parameters ]
Chassis Model
EQ1060TJ20D3
Chassis Brand
DONGFENG
Overall Dimension(mm)
5850 × 1960 ×2 550
Tyre No.
6
App/Dep Angle(°)
19/15
Tyre Specification
6.50-16
Spring Leaf No.
8 / 9 + 5
Front Track(mm)
1 506
Fuel Type
Diesel
Rear Track(mm)
1 442
Emission Standard
EURO II
Engine Model
YC4F90-30
Engine Brand
Yu  Chai
Power
90hp/66kw
Displacement(ml)
2659
