• Payload：20T
• Fuel：Diesel
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Color：Green, Yellow, White, Red, Black.etc
• Driver Seat：Air Suspension Seat
• Configuration：Can Be Changed as You Request
• Transport Package：Nude Packing After Painted Wax
• Specification：11000x2500x4000mm
• Trademark：SINOTRUK-HOWO
• Origin：China
• HS Code：8705400000
• Production Capacity：3000nuits,Month

Product Specifications
Engine model
WD615.93C
Engine Power
290HP
Displacement
9726ml
Fuel Type
Diesel
Emission standard
Euro III
Overall dimension
(L*W*H)
8375*2496*3950mm
Wheelbase
3200+1350mm
Minimum turning circle
20
Curb weight(kg)
12300
Max speed(km/h)
90
Fuel tank capacity(L)
300
Fuel type
Diesel
Transmission model
HW15710
Steering system
ZF8098
Front axle
HF9
Rear axle
HC16
Tyre
12.00-20(10+1spare)
Brake system
Service
Dual circuit compressed air brake
Parking
Spring energy, compressed air operating on rear wheels
Auxiliary
Engine exhaust brake
Electrical system
Battery
2X12V/165Ah
Alternator
28V-1500kw
Starter
7.5Kw/24V
Cab
HW76 cab, (one sleeper, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.
Geometric Volume
13.5m3
Agitating Capacity
8m3
Drum rotating
14°
Agitator rotaion speed
0-14r/min
Feeding speed
>3.5m3/min
Water Tank Volume
400L
Discharge remain ratio
<0.2%Q1: I want the front two tires are bias tires and the rear 9 tires are radial tires, is it ok ?   A: We can make the tires as your requirement to suit your country's need.Q2: What about your products quality ?      A: Quality is our culture! "Our factory has advanced production technology and management team!
   We always attach great importance to quality controlling from the very beginning!Q 3: Can i have samples of this type of flatbed semi trailer to test the quality ?        A: Yes, you can buy any samples to test the quality,our MOQ is 1 unit.Q 4: What others we can do ?   A: According to your order, we will provide the best price and quality trucks and trailers.
   And we are well capable in offering overseas after-sales service. Besides, we also provide rational
   packing and shipping program,let shipment save money and security.Q 5: How to guarantee customers get the goods smoothly after they pay ?   A: Don't worry, dear. We have been in this field for 10 years, we will send you production photos once in a while, and we will help you to book the latest ship.Q 6: What's the delivery time ?   A: The delivery time is within 15 working days after receiving your advance payment. Q 7: Can you supply some quick-wear truck or semi trailer parts ?   A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance   beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads,   brake pan, bearings etc. Q 8:  Do you have any used truck and semi trailer for sale ?   A: We have some trucks and trailers in stock for choice, from 2010-2016 year, the price are favorable. We'll
   show you our stock if you need. Q 9:  Which INCOTERMS 2010 TERMS can we work ?   MAOWO is a professional and sophisticated international player, can handle all INCOTERMS
   2010 terms, and we normally work on FOB, CFR, CIF, CIP, EXW. Q 10:  What logistics ways we can work for shipment?   A: We can ship construction machinery by various transportation tools.
   (1) For 80% of our shipment, we will go by sea, to all main continents such as South America,
   Middle East, Africa, Oceania etc. Either by container or RoRo/Bulk shipment.
   (2) For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan , Vietnam, Laos  etc.,we can ship construction machinery by road or railway.
   (3) For light spare parts in urgent demand, we can ship it by international courier service, such as
   DHL, TNT, UPS, or Fedex.
6. Main products



8. Warranty
(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.
