• Model NO.：3m3
• Volume of Tank：5m3
• Mixing Volume：3m3
• Inclination of Tank：16°
• Washing：High Pressure Washing
• Engine：Cummins,Weichai,Yuchai
• Productivity：Batch≤15mins 4batches,Hour
• Transport Package：Standard Packing for International Transport
• Trademark：FOCUS Self Loading Concrete Mixing Truck
• Origin：Zhengzhou, China
• HS Code：8474310000
• Production Capacity：120 Sets Per Month

ModelFSB3FChassisFSD3-2000TypeMovable, self loading, mixing, transportingFunctionConcrete, sand,  fertilizer compound, wet or dry feed materials mixing and dischargingProductivityBatch≤15mins,  4Batches/HourSteering4 wheelsEngineCummins/Weichai/YuchaiSpeedHigh speed: 22.4km/h; Low speed:6.5 km/hWheel Base2000mmTread1833mmTire10.00-20(project machine tire) 4 pcsVolume of tank5m3Mixing volume3m3Mixing bladesDouble spiral mixing blades, Feeding: Left, Discharging: RightInclination of tank16°Discharge ChuteHeight:1.6m, speed≤3r/min, angle:270°Tipping ChuteAdjustable angle, 2-segment tipping chute can be dismantled, can expand the discharging lengthShovelShovel capacity: 600LDischarging of shovelHydraulic, electric control.Operation handleElectric control, Button four-way guide handleMotorREXROTH/ChinaSPEED REDUCERFX300Water SupplyHydraulic driving self priming pumps
Washing: High-pressure water pump washWashingHigh pressure washingWeighing systemInclude touch screen, controller, weighing sensor, water flow sensor, etc.
Main functions:
1. Weighing the materials or water when fed by fed by shovel
2. Recipes management and one key choosing function.
3. During the weighing process, auto-suggestion when it is close to the target value.
4. Data and report forms are generated automatically, easy to refer and export data by USB disk.
5. With Printer.VoltageBattery 24v, 200AHydraulic Oil TankTank:300L, Summer:No.68 Hydraulic Oil, Winter:No.46 Hydraulic Oil, Very cold zone: No.35 Hydraulic OilWater Tank300LDiesel tank112LMassCurb weight:7000kg, Total weight:14200kgDriver's cabStreamline cab, windshield can be opened.DimensionMoving state: L*W*H=5400x2530x4300mmShovel state: L*W*H=7100x2530x3100mmAlarm LampStandard ConfigurationRadioStandard ConfigurationAir-conditioner of cabStandard ConfigurationEscape HammerStandard ConfigurationCoat RackStandard ConfigurationHead lightLED high lightBack lightLED high lightForward gearElectric controlHigh/low speedElectric controlFour wheelsStandard ConfigurationHydraulic pipesStandard ConfigurationThanks for visiting, by the time you are paying attention to us, our self loading concrete mixing truck  are being delivered /distributed to the world everyday - it'll be such a great honor if you can join us.
