• Model NO.：FOCUS 3M3 4M3 6M3
• Drive Mode：4x2
• Condition：New
• Weight：7t
• Mixer Volume：3cbm,4cbm,6cbm
• Power(W)：103kw 140PS
• Dimension(L*W*H)：7370X2500X3650mm
• Engine Manufacturer：Yuchai Machinery Co
• Water Supply：450L Tank with Reinforced Pipe
• Concrete Truck Mixer Welding：Spot Welding
• Radiator：Emergency Switch Installed
• Coating&Painting：Bus Baking Varnish Standard
• Transport Package：Bulk Ship or Roro Ship
• Specification：CE, ISO9001: 2008
• Trademark：Focus
• Origin：Zhengzhou China
• HS Code：8705400000
• Production Capacity：28sets,Month

[Main Technical Parameter]
Chassis Brand
DONGFENG
Batch No.
257
Product Name
DLQ5150GJBG4 Concrete Mixer Truck
Truck Model
ZL2S54D701L
Total weight(Kg)
14960
Tank Volume(m3)
4
Rated Load(Kg)
8785
Dimension(mm)
6650x2460x3380
Curb Weight(Kg)
5980
Passenger(person)
3
Approach angle/departure angle(°)
22/20
Front overhang/rear overhang(mm)
1180/2070
Axel No.
2
Wheelbase(mm)
3400
axle load (Kg)
5050/9910
Max. Speed(Km/h)
90
Other
Mixing Volume:3m3
Material of side and below protective device:Q235-A,
Connection type: Bolt Connection
Height of back protective device:510mm
[Chassis Parameter]
Chassis Model
EQ1168GLJ3
Brand
DONGFENG
Dimension(mm)
6570x2100x2550
Quantity of Tire
6
Approach angle/departure angle(°)
22/17
Tire specification
8.25-16
Steel Spring No.
9/11+8
Front Tread(mm)
1810
Fuel
Diesel
Back Tread(mm)
1800
EMISSION STANDARD
Euro III
Engine Model
Engine Manufacturer
Displacement(ml)
Power(Kw)
YC4D140-45
Yuchai Machinery Co.,Ltd
4214
103
