8X4 Isuzu 39m 43m 46m 47m 49m 51m Concrete Pump Truck

Hubei Weiyu Special Vehicles Co., Ltd.
  • Certification：ISO9000, CCC, SGS BV Soncap
  • Transmission Type：Manual
  • Emission Standard：Euro 3,Euro 4
  • Displacement：9726cc
  • Payload：46m 47m
  • Fuel：Diesel

Base Info

  • Model NO.：CLW9400BC
  • Drive Mode：6X4,8X4
  • Maximum Horsepower：300-400hp
  • Condition：New
  • Wheelbase：1850+4605+1310
  • Steering Wheel：Left Hand Drive
  • Delivery Time：20-60days
  • Manufacturing Year：New Condition
  • Fuel Type：Diesel
  • Testing：Products Inspection Before Shipment
  • Warranty：1 Year
  • Certificate：ISO CCC BV SGS
  • Maximum Cloth Height (M)：46.6
  • Maximum Cloth Radius (M)：42.6
  • Maximum Cloth Depth (M)：36.8
  • Rotation Angle(°)：365
  • Arm Number：5
  • Arm Section Length (mm)：9885,8115,8115, 8220,8455
  • Pipe Diameter (mm)：125
  • Transport Package：Naked, Waxed, Bulk Ship, RO-RO
  • Specification：12750*2490*3990mm
  • Trademark：CLW
  • Origin：China
  • HS Code：8704230090
  • Production Capacity：300 Unit in Stock

Description

Chassis and vehicleChassis modelCYH51YDriving method8×4, left steeringWheelbase mm1850+4605+1310engine model6WF1DMaximum engine power kW/(r/min)287/1800Maximum engine torque N.m/(r/min)1863/1100Engine capacity (cc)14.256Fuel typeDieselFuel tank capacity (L)400Exhaust emission standardsEURO IIIMaximum vehicle speed (km/h)89Mass of completed vehicle (kg)3900Overall dimensions (length × width × height) (mm)12750×2490×3990
Reference Picture
8X4 Isuzu 39m 43m 46m 47m 49m 51m Concrete Pump Truck

Successful Case
8X4 Isuzu 39m 43m 46m 47m 49m 51m Concrete Pump Truck

Customer Inspection
8X4 Isuzu 39m 43m 46m 47m 49m 51m Concrete Pump Truck

Overseas Exhibition and After-sales Service
8X4 Isuzu 39m 43m 46m 47m 49m 51m Concrete Pump Truck
