• Model NO.：Mobile Repair Workshop
• Transport Package：Nil
• Specification：military standard.
• Trademark：Dongrun Ze
• Origin：China
• HS Code：8705909990
• Production Capacity：10000

Tool TruckDrive Model4X2Vehicle Main DimensionsDimensions(L x W x H)mm6000x2250x2900Wheel base (mm)3360Weight in KGSCurb Weight4000GVW.8000Max. driving speed(km/h)94EngineModelYN4100Type4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)110HPEmission standardEuro IIGearbox5 forwards & 1 reverseSteering GearPower steering, hydraulic steering with power assistanceTire7.00R16 all steel radial tyre with one spareBrakesdual circuit compressed air brakeVanMaterial

 Steel





HOWO Workshop Tool Truck 160HP



Technical parameters

Driving type 4*2 LHD/RHD

Model ZZ

2080mm cabin, 1bed, AC

Overall Size(mm)8500*2500*2850Platform Size(mm)1100X570X1000mmWheel base(mm)5200GVW(kg)12000Front axle loading capacity(kg)1*3800Rear axle loading capacity(kg)2*10500EngineBrandYuChaiModelYC4E160-33TypeDiesel, 4-cylinder in-line with water cooling,
turbo-charging and inter-coolingDisplacement4.257LBore*Stroke102*118mmHose Power(HP)160HPEmission standardEuro 2Max speed72km/hTire9.00R20 radial tires ,7pcs including 1 spare tireTransmissionDC6J65TC gear box, with 6 forward and 1 reverseSteeringpower steeringOil tank220L Aluminum alloy fuel tankBrake system

Service brake: dual circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake



Electrics

Operating voltage:24V,negative grounded

Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light

Options

Vertical Muffler;

ABS;

Automatic Break Clearance Adjusting Arm;

Traveling Data;

ZF Gearbox

PTO

Sinotruk Howo 6x4 Road Repair Mobile Workshop Maintenance Truck for Sale



HOWO Vehicle Mobile Workshop 6x4

Max WG:29000kg  ZZ1257N4341W

Complete
Vehicle

Tare Weight

16,000 Kg

Loading Capacity

13000 Kg

Drive Type

6X4

Tyres

10+ 1; 12.00R20 STEEL TYRE,

Max. Speed

75 KPH

Max. Gradeability

40%

Minimum Ground Clearance

298 mm

Overall Dimensions

9890,10350 x 2520 x 3660 mm

Wheel Base

4325+1350 ;4600+1350 mm

Fuel Tank Capacity

300L

Engine

WD615.62; WD615.92;(D12.27) 6 Cylinder in Line, Water Cooling Diesel Engine, Turbo Charged with Intercooler; 266hp/2200rpm;

Gearbox

FULLER RT-11509C; 9 Forwards & 1 Reverse

Equipment

Power Set
(Generator)

Model: 40GF ; Rated Power 40KW; Voltage 400/230V;
Frequency 50 Hz; Rated Current 72.2A; 3-Phase 4-Line;
Diesel Engine R4100ZD; Generator TZH-40

Welding Set

Model: ZX7 SCR  , (ZX5-250B); Voltage 380V; Initial Current 29.6A;
Range 25 ~ 250 A; Input 19.2 KVA

Air Compressor

Model: AW3608; Voltage 380V; Power 3KW;
Pressure 0.7MPa; Capacity 0.36M3/mm

Drilling Machine

Model: ZQJ4119AD; Bore Range 3 ~ 16mm; Power 700W

Vice

Size: 150mm

Grinding Machine

Model: MQ3225; Size 250mm; Power 700W

Gas Welding & Cutting Set

Oxygen Cylinder 40L; Accetylene Cylinder 20L

Working Bench

Steel Panel, 2,300mm x 550mm x 780mm

Lifting Device

Roof Mounted, Retractable Cantilever, 2-Ton Chain Block

General tools

2 sets

Working light

15m

Color: green

SINOTRUK Mobile Workshop Truck


Equipment for Mobile Workshop   5190YX
Item
Description
Technical Data
Measurement
Weight
Qty.
1
Chassis
As Option
2
Power Set
(Generator)
Model: 40GF74-4
2030x650x1255(mm)
1030kg
1
Rated Power: 40KW
Rated Voltage: 400/230V
Rated Frequency: 50Hz
Rated Current: 72.2A
Output: 3-phase, 4-line
Diesel Engine: R4100ZD
Generator Model: TZH-40
3
Welding Set
Model: ZX5-250B
406x530x840(mm)
160kg
1
Voltage: 380V
Phase: 3
Frequency: 50/60Hz
Initial Current: 29.6A
Range: 25-250A
Input: 19.2KVA
Working Ambient: -10--+40oC
4
Air Compressor
Model: AW3608
1180x410x850(mm)
130kg
1
Voltage: 380V
Frequency: 50Hz
Power: 3KW
Pressure: 0.7MPa
Capacity: 0.36M3/mm
5
Drilling Machine
Model: ZQJ4119AD
760x490x260(mm)
57kg
1
Bore Range: 3--16mm
Power: 700W
6
Vice
Size: 150mm
7
Grinding Machine
Model: MQ3225
1
Size: 250mm
Power: 700W
8
Oxygen Cylinder
Volume: 40L
1
9
Acetylene Cylinder
1
10
Gas Welding Set
1
11
Working Bench
Steel Panel
2300x550x780(mm)
1
12
Hand Tools
M6--16 drilling set; Hack Saw;
Hammer; Portable Oil Pump;
3--16mm Thread Tapper;
Spanner sets; Socket Spanner Sets
Files; Clamps
Tools

No
Name
         Specification
Quantity
1
Bow saw frame
2
2
Hacksaw blade
18 tine; 32 tine
Each 1
3
Manual   oil gun
1
4
Oil pot
300cc
1
5
Hand electric   drill
220V   0.6~6mm
1
6
Pipe expansion ware
1 set
7
Electrical   maintenance kits
with multimeter
1 set
8
Screw tap
Coarse thread
6/set
9
Screw tap
Fine thread
3/set
10
Screw tap holder
180mm;280mm
each   1 set
11
Screw die
Coarse thread
6/set
12
Screw die
Fine thread
3/set
13
Drill
1-10mm                       (at intervals of)0.5mm
2set
14
Drill
11-16mm
2sets
15
Drill
3.4;4.2;5.1;6.8;8.5;10.2
each   1 set
16
Steel ruler
150mm,300mm
Each 1
17
Vernier   caliper
150mm,250mm
1
18
Screw thread gauge
the metric system; British system
each   1
19
Tape
2m
1
20
Round head hammer
2.5 pound
1
21
File
roundness,semi-circle,flat,square
,triangle
Each 2
22
Assorted set of files
2 sets
23
Screwdriver
cross 125mm;minus 125mm
each 1
24
Pointed plier
150mm
1
25
Steel wire clamp
200mm
1
26
Carp clamp
200mm
1
27
Oxygen watch
1
28
Acetylene watch
1set
29
Welding wire clip
500A
1
30
White glass
10
31
Protection glasses
1
32
Steel brush
1
33
Emery cloth
46#;80#;120#
each 10
34
Metric fixed wrench
10/set
1 set
35
Metric ring wrench
10/set
1 set
36
Wrench
8";10";12"
each 1
37
Round head hammer
1.5 pound
1
38
Welding torch

1
39
Cut torch

1
40
Oxygen tube
30m
1
41
Acetylene tube
30m
1
42
Hand electric drill
220V 3-19mm
1
43
Jack
10T
1
44
Socket wrench
8mm-32mm
32/set
45
Cut clamp
medium-sized
1
46
Welding gloves

1
47



48
Work Light

1
49
Welding mask

1










Equipments:

50Kw generator, air conoressor, charger, portable generator, are welding machine, plasma cutting machine, eletric winch, desk drill, desk grinding machine, 1 ton crane, 200kg hand chain hoist and slide rail, pneumatic tyre spanner

maintenance vehicle,Emergency repair car,road service car,maintenance truck

Hydraulic drive, reliable, safe and noise-free;
Latest fan-shaped nozzle, three overlapping design;

High power rear lights for night operation

option 2

Device	Model	Specifications	Dimensions
Chassis	ZZ2152M4367LA ZZ2152M4367LA
Pressure Washer	DL40-type	22L/MINPressure:210kg Flow: 22L/MIN Motor:11kw Spray gun: 1 unit High-pressure hose:10 m nozzle: 5 unit 350kgWeight:350kg	Length:1500mm Width:650mm Height:500mm
Oil drum with a suction pump	JK-3BGeneral	40L/minPower:0.12kw Flow: 40L/min Head:2.5m Entrance and Exit: 25/32mm Voltage:220V
40KWdiesel generator set	40GF-440GF-4 Engine Model: R4110D40-1 Generator Type:TZH-40	Rated Power:40kw Rated Voltage:400/230V Rated Frequency:50HZ Rated current: 72.2A Output Mode:3-phase 4-wire Weight:850kg	1820- x636x - 1320
ZX7SCRWelding Machine	ZX7-400SZX7-400S	Voltage:380V, 3 phase, 50/60HZ CurrentRange:25-250A Input Capacity: 14.5KVA Working environment:-10 ~ +40. C C	475-x 280 -x 400
