• Payload：20T
• Fuel：Diesel
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Carriage Volume：8 Cbm
• Weight：13220 Kg
• Engine：Wp10.340e32
• Gearbox：Hw19710
• Wheel Base：3800+1350mm
• Fuel Type：Diesel
• Tire Specifications：318,80,R22.5
• Number of Tyres：10+1 Spare Tire
• Type of Water Supply：Air Pressure
• Transport Package：Suitable Package for Shipment
• Specification：Within 15days delivery
• Trademark：Shacman
• Origin：Jinan, China
• HS Code：87054000
• Production Capacity：500 Set,Sets , Month

Carriage volume8m³Dimension(Lx W xH)(unloaded)(mm)9040×2496×3850Approaching angle/Departure angle(°)19/23Overhang(front/rear) (mm)1500/1870Wheel base (mm)3800+1350Max speed(km/h)(km/h)75Curb weight(kg)13220Engine
(Steyr technology, made in China)ModelWD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injectionFuel type   Diesel Power, max(kw/rpm)247/2200EmissionEURO IIFuel tanker capacity(L)300TransmissionModelHW15710,10 forward&2 reverseBrake systemService brakeDual circuit compressed air brakeParking brakespring energy, compressed air operating on rear wheelsSteering systemModelZF8098Front axleHF9Rear axleHC16Tyre12.00R20Electrical systemBattery2X12V/165AhAlternator28V-1500kwStarter7.5Kw/24VCab76 cab(Single beds,A/C),all-steel forward control,55º hydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.
