Customizing 40 T Offorad HOWO Mining Dust Control Water Cannon Spray Tanker Truck 6X4/6X6
Hubei Dong Runze Special Vehicle Equipment Co., Ltd.- After-sales Service：24hours
- Warranty：24months
- Volume：＞30000L
- Certification：ISO9000, CCC
- Emission Standard：Euro 3-5 -6 -7
- Sprinkling Area：＞16m
Base Info
- Model NO.：HOWO Mining Water Tanker
- Transmission Type：Manual
- Payload：20T
- Fuel：Diesel
- Drive Wheel：6×4
- Engine Capacity：＞8L
- Condition：New
- Tire：13.00-25
- Cabin：HOWO
- Fuel Tank(L)：400L
- Tank Volume：30-40m3
- Dimensions：11500X3280X3630 mm
- Transport Package：Nil
- Specification：Dust Suppression Unit standard
- Trademark：DRZ
- Origin：China
- HS Code：8705909990
- Production Capacity：10000
Description
GVW 60000kg Driving Type 6x4 Engine 9.726 Engine 9.726 2 nos of duck-billed sprinklers (in front), 2 nos of cylindrical sprinklers (at rear), 2 nos of 2.5" pressure water discharge, 1 nos of 3" water sucking mouth, 1 nos of high shooting spray rod, 2 nos of 3" 3m pipe, 1.ParameterModel DRZ5707GSSZ Cab HOWO7D cab, mining cab Engine(Hp) 370 Power(Kw) 273 Wheelbase 3800+1500 Front/Rear Suspension 1500/ 2600 Steering Power steering Approach/departure angle 32/40 Wheels & tire 14.00-25 Tire number 10+1 Tank Dimensions(mm) Cubage (m3) 40 Steel thickness of tank(mm) 5 RHD or LHD optional Overall Dimensions(mm) 10000x3165x3900 Curb weight (Kg) 25000 Engine Model WD615.47 Horsepower 370 Maximum output Kw 273 Maximum torque N.m Type 6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine Displacement 9.726L Sinotruk brand, Euro 2 Driving passenger 2,3 Transmission HW19710,10 forwards,2 reverse Front Axle HF 9 Rear Axle HC 16 Brake System air brake Color and LOGO customized Electric system 24V Tank material Carbon steel, stainless steel, aluminum, etc. alloy, etc. Sprinkler width 14m each side Suction height 7m Standard configuration carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder. Optional configuration Stainless steel/aluminum alloy water tank, insulation layer for water tank, stainless steel water pump, fire pump, fire gun, pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights Delivery date Within 20 days after receipt advance Packing Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. Model ZZ5707S4640AJ Cabin HW7D, with one seat, with Air Conditioner Model WD615.47 Horse Power (Hp/rpm) 371/2000, Euro II Emission Standard Max.Toruqe(Nm/rpm) 1460/1200-1500 Displacement L Type 6-cylinder in-line with water cooling, turbo charger and intercooling, 4-stroke direct injection diesel engine Transmission HW19710, 10 speeds forward and 2 speeds reverse. Front Axle HF10, Steering with double T-cross section beam, Loading Capacity: 10,000kgs Driving Axle AC16, Pressed axle housing, central reduction, Loading Capacity: 4,200kgs Suspension Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs, bogie spring and stabilizer Steering System Hydraulic steering with power assistance Brake System Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake Tire 13.00-25 Fuel Tank Capacity (L) 500L Diesel Tank Kurb Weight (kg) 20,000 Loading Capacity (kg) 35,000 Gross Vehicle Weight (kg) 55,000 Overall Dimension(L*W*H)(mm) 9600×3000×3400 Tank Capacity(L) 35,000 Tank Material Carbon Steel Nos of Compartment 1 Wheelbase(mm) 4600+1500 Max. Speed (km/h) 35 Model ZZ2257N4657A Cabin HW76 Long Cab, with two seats and one bed, with Air Conditioner and electric window. Model WD615.47 Horse Power (Hp/rpm) 371/2000, Euro II Emission Standard Max.Toruqe(Nm/rpm) 1460/1200-1500 Displacement L Type 6-cylinder in-line with water cooling, turbo charger and intercooling, 4-stroke common raildiesel engine Transmission HW19710, 10 speeds forward and 2 speeds reverse. Front Axle HF9, Steering with double T-cross section beam, Loading Capacity: 9,000kgs Driving Axle HC16, Pressed axle housing, central reduction with hub reduction, with differential locks between wheels and axles. ratio: 4.8. Option: 4.42 Suspension Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension:leaf semi-elliptic springs, bogie spring and stabilizer Steering System ZF8118, Hydraulic steering with power assistance Brake System Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake Tire 12.00R20 Fuel Tank Capacity (L) 400L Diesel Tank Kurb Weight (kg) 12,800 Loading Capacity (kg) 28,200 Gross Vehicle Weight (kg) 41,000 Overall Dimension(L*W*H)(mm) 10200×2500×3320 Tank Capacity(L) 20,000 Tank Material Carbon Steel Nos of Compartment 1 Accessories Wheelbase(mm) 4625+1350 Max. Speed (km/h) 90
General Truck Name: SINOTRUK HOWO WATER TRUCK Curb weight(kg) 12500 Fact loading(kg) 18000 Overall size(mm) 9750×2500×3350 Cab Cab allowance 2 seat with 1 bed Air condition(hot/cool) Yes
ChassisF/R overhang(mm) 1500/2425 Fuel type: Diesel Engine manufacturer/model Sinotruk diesel engine/WD615 87 Power 213kw/290hp Displacement 9726ml Transmission HW13710(10 forward 2 reverse) Emission standard EURO 2 F/R tread(mm) 2041/1830 Tank size(mm) 6280*2350*1680 Approach/departure angle 16/20 Wheelbase(mm) 4300+1350 Axle load 7000/16000/16000 Tire specification/No. 12.00-20 Max speed(km/h) 95km/h Number of axles 3 Spring leaf no(F/R) 9/10 Others Transport medium:Water;Valid capacity by tank:20,000L
Tank made material carbon steel Q235, 5mm
Equipped with water pump,OPO drive pump self suction water,fire valve, water valve both side, and filter gauze safety ladder, water pipe 2 pcs , manhole, tool box, gravity valve and so on
ater truck special function
A. Water tank capacity(L):16000L 25,000 Liters
B. Sprinkling area(m):14-16m
C. Suction lift(m):≥7m
Water cannon range description
Water cannon installed on the rear of the truck,also
with operation platform,that operator can work on
the platform.It can be used to clean road,trees,and
also for emergency fire fighting.
Water cannon range:≥60m,it can rotation with 360°
degree freely
Manhole size(mm)
Man way access hole on top of tank; manhole
diameter:¢500mm
Front spray function
Front spray bar with fan sprayer,spray range: ≥20m
Man walk way
With skid resistance man walk way on top of tank
Water pump model
80QZB(F)-60/90S
Flow rate(L/m)
1000
Head of delivery(m)
60
Shaft power
22.5
Suction height (m)
6.5
Efficiency(%)
95%
| Model | DS-60 |
| Throw | ≥60m |
| Volume Flow | 70L-80L/min |
| Fog Droplet Size (Adjustable ) | 30-150 µm |
| Water Pressure(Mpa) | 2.0~3.5Mpa |
| Water Pressure(bar) | 20-35bar |
| Water Pressure(kg) | 20-35kg |
| Motor RPM | 2900 |
| Horizontal Rotation Angle | ±160° Automatic |
| Pitching Angle | -10°~45° |
| Coverage Area | 8,000 ~10,000m2 |
| Product Size ( L * W * H) | L220 * W154 * H239 (cm) |
| Vehicle Matching | Agricultural vehicle,truck,watering cart,trailed vehicle, etc. |
| Water Tank Capacity (Optional) | 4000-20000L |
