• Model NO.：GKS18
• Payload：200kg
• Fuel：Diesel
• Transmission Type：Automatic
• Drive Wheel：4x2
• Condition：New
• Model：Xgs5041jgkj6
• Engine Model：Jx4d30b6h
• Chassis Model：Jx1041tcd26
• Power：85kw
• Number of Passengers：2
• Max.Working Height：17.3m
• Max.Working Radius：11.6m
• Slewing Angle：360
• Slewing Angle-Rear：122
• Transport Package：Nude Package
• Specification：5995*2070*2950mm
• Trademark：CRUKING
• Origin：China
• HS Code：8429510000
• Production Capacity：500sets,Year

Basic Info.

Model NO. GKS18 Payload 200kg Fuel Diesel Transmission Type Automatic Drive Wheel 4x2 Condition New Model Xgs5041jgkj6 Engine Model Jx4d30b6h Chassis Model Jx1041tcd26 Power 85kw Number of Passengers 2 Max.Working Height 17.3m Max.Working Radius 11.6m Slewing Angle 360 Slewing Angle-Rear 122 Transport Package Nude Package Specification 5995*2070*2950mm Trademark CRUKING Origin China HS Code 8429510000 Production Capacity 500sets/Year

Product Description

Extensible Boom Aerial Device GKS18Product Features

The maximum working height of the extensible boom aerial device is superior to all others at the domestic same level, with high efficiency and wide operation range. The product equipped with CAN bus intelligent control system can achieve flexible operation and all-round security restriction and protection, with independent intellectual property rights, patented technology of built-in pipeline conveyer, realized the project of built-in extension cylinder, pipeline, and circuit improved the equipment safety and convenience operation of small space.

Main Specification

Item	Unit	Parameter
Model	-	XGS5041JGKJ6
L*W*H	mm	5995*2070*2950
Model of chassis	-	JX1041TCD26
Model of engine	-	JX4D30B6H
Power	kW	85
Number of passengers	-	2
Max. working height	m	17.3
Max. working radius	m	11.6
Rated load	kg	200
