• Model NO.：SG180
• Fuel：Diesel
• Drive Wheel：6×4
• Horsepower：251-350hp
• Condition：New
• Lateral Outrigger Span：8m
• Max. Travel Speed：90km,H
• Weight (Kg)：25000 Kg
• Transport Package：Container Bulk Nude Frame
• Specification：25000kg
• Trademark：china top
• Origin：China
• HS Code：8426910000
• Production Capacity：100pieces,Month

Brief CodeSG180Overall Measurement (L*W*H)(mm)10430*2500*3680Chassis BrandSINOTRUKDriving form6*4Wheel Base (mm)4600+1350Curb Mass (kg)15440GVW (kg)33490Water Tank Capacity (L)17600Engine Power (kW)276Power Density (kW/t)8.2Max Vehicle Speed (km/h)80Min Turning Diameter (m)22Fire Pump ModelCB20.10/30.60-XZMonitor ModelPS50Water Pump Flow (L/s)60/30Water Pump Pressure (Mpa)1.0/2.0Monitor Flow Rate (L/s)50Monitor Range (m)≥65Water Pumper Inlet Diameter (mm)1*150Water Pumper Outlet Diameter (mm)4*80(normal pressure)
& 2*65(medium pressure)Water Tank Inlet Diameter (mm)4*80Proportioning MixerWithoutDriver's Cab (persons)6
