• Transmission Type：Manual
• Drive Wheel：4x2
• Condition：New
• Working Height：6-22m
• Working Radius：4-15m
• Rotating Speed：0-2 R,Min
• Rotation Angle：360
• Bucket Loading：200kg
• Hook Loading：1000kg
• Supporting Leg：Hydraulic
• Boom Type：Folading or Telescopic
• Control Mode：Hydraulic or Electronic
• Bucket Size：1200*600*1100mm
• Bucket Type：Insulated
• Transport Package：Nude Packing with Wax
• Specification：6990*2100*2500
• Trademark：CLW
• Origin：China
• HS Code：87059099
• Production Capacity：200unit Per Month

Chassis Specification

Truck model

CLW5050JGKIS18T

Cab

ISUZU 100P single row seat cab

Driving Type

4*2 Left hand driving

Max Speed (km/h)

90

Overall dimension (mm)

7350*2080*2920

GVW (kg)

Appro. 5555

Mass in working order( kg)

Appro. 5335

Wheelbase (mm)

3360

F/R track base (mm)

1504/1425

F/R overhang(mm)

1065/2125

Approach/Departure Angel

27/15

Tire

7.00-16

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

MSB 5-speed

Bridge

Front axle

2.5T

Rear axle

4.8T

Engine

Model

4JB1CN

Fuel Type

Diesel fuel

Emission Standard

Europe 4

Type

Water-cooled four-stroke, supercharged inter-cooling

Exhaust (ml)

2771

Max output power/rotate speed (hp /rpm )

98/3400

Max torque/rotate speed (N.m/rpm)

220/1700

BrakingSystem

Service Brake

Oil brake

Park Brake

Spring energy

Electric system

24v

Special Function

Working height (m)

8

Max working radius (m)

6

Boom type

Two sections telescopic boom

Rated loading in the bucket(kg)

200

Bucket size (mm)

1000*650*1200

Rotating speed (r/min)

0-2

Rotation Angle

360°

Supporting leg

foursetshydraulic legs

Span of supporting legs

Horizontal

3500mm

longitudinal

4000mm

Boom Control mode

1.Bucket control

2.Manual operation

Supporting leg Control mode

Manual operation

Working Condition:

1.Altitude: 0-4500m

2.Temperature: -350C~+450C

3.Relative humidity: 80%

4.Wind force: ≤8 degree
