Sinotruk New HOWO 4X2 8 Cbm Sewage Suction Truck
Sinotruk Hubei Huawin Imp. & Exp. Co., Ltd.- After-sales Service:24 Hours After-Sale Service
- Warranty:12 Months
- Certification:ISO9000, CCC, TS16949
- Emission Standard:Euro 2
- Payload:16 Ton
- Transmission Type:Manual
Base Info
- Model NO.:ZZ
- Fuel:Diesel
- Tank Volume:16000 L
- Drive Wheel:4x2
- Hoesrpower:150-250hp
- Condition:New
- Engine Brand:Cummins
- Engine Capacity:5900 Cc
- Max Torque:640 N.M
- Gearbox:Fast 8-Speed
- Transport Package:Waxed Before on Board
- Specification:8000 litres
- Trademark:DF
- Origin:China
- HS Code:8704
- Production Capacity:200 Sets Per Month
Description
Overview
Vehicle Main Dimensions Overall dimensions (L x W x H)mm 7500×2500×3200 Wheel base (mm) 4500 Wheel track (front/rear) (mm) 1940/1860 Weight in KGS Tare Weight 7000 payload 10000 Front axles loading capacity 1x6000 Rear axles loading capacity 1x12000 Max. driving speed(km/h) 90 Engine Brand Cummins Model B190 Type 4-stroke direct injection , 6-cylinder in-line , turbo-charging and inter-cooling Horse Power(HP) 190 HP Emission standard Euro II Gearbox 6 Forwards gear & 1 reverse gear Steering power steering Tire 10.00-20 tyre with one spare Tank Specifications 1, 8000 vacuum tank body made of high tensile steel
2, Equipped with twin vacuum pump(rating rotate speed=1400r/m,min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise)
3, Time for full suction: 5 minutes
4, Hydraulic system adopted for lifting tank body and opening tank end cover.
Shipping
Contact us
Welcome you come to china and visit our factory .
