Isuzu Giga 10 Wheels 6X4 Lift Garage Truck 20cbm Rear Hook Loader for Sale
CIMC VEHICLES SALES CO., LTD.- After-sales Service：All Genuine Parts Available
- Warranty：1 Year
- Type：Garbage Compactor Truck
- Certification：ISO9000, CCC, TS16949
- Volume：＞15000L
- Emission Standard：Euro 4
Base Info
- Transmission Type：Manual
- Payload：20T
- Fuel：Diesel
- Drive Wheel：6×4
- Brand：Isuzu
- Models：Large
- Usage：Compression Type
- Condition：New
- Engine：6uz1-Tcg40
- Transmission：Fast 9js150ta-B
- Cabin：Isuzu Vc46
- Wheelbase：4605+1300 mm
- Tire Size：295,80r22.5
- Front Axle：Isuzu F075
- Rear Axle：Isuzu Rt210
- Rear Axle Ratio：4.555
- Compactor Body：20m3
- Volume of Filler(M3)：2.5
- Front/Rear Sewage Capacity (L)：250+150
- Time of One Filling Cycle(S)：Less Than 25s
- Lifting Time of Filler (S)：8-10s
- Max Compression Force (Kg)：>35000
- Pressure of Fluid System (MPa)：20
- Transport Package：Nude Packing
- Specification：ISO, TS16949, CCC
- Trademark：ISUZU
- Origin：China
- HS Code：8704230000
- Production Capacity：1000PCS,Month
Description
ModelQL1250UTCZY Driving type: 6*4 left hand driving Engine Make: ISUZU Diesel 4-stroke direct injection diesel engine, electronic control Engine model:6UZ1-TCG40, Euro IV emission standard 6-cylinder in-line with water cooled, turbo-charging and intercooler Maximum output: 350HP-380HP/257KW-279KW Maximum torque: 1450 Nm Displacement: 9.8 L Transmission FAST 9JS150TA-B, 9 forwards and 1 reverse,manual Ratio:12.65 8.38 6.22 4.57 3.40 2.46 1.83 1.34 1 13.22 (R) Front Axle ISUZU F075, 7.5 Ton loading Capacity Rear Axle ISUZU RT210,21 Ton loading capacity,speed ratio 5.571 Chassis Frame: U-profile parallel ladder frame and reinforced subframe with size 320×90×8 MM Front suspension:12 semi-elliptic leaf spring Rear suspension:12 semi-elliptic lea spring Aluminium fuel tank: 400 L capacity with locking fuel cap, fitted to the off side of the chassis Steering Power steering, hydraulic steering with power assitance Brakes Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels ABS Wheels & Tyres Tire: 11 pcs 11.00-20 Option:11.00R20, 295/80R22.5 Driver's Cab ISUZU Flat roof cab, with two seats, 1 bed, A/C, electric glass, central lock Electrics Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light Dimensions mm Wheel base 4605+1300 MM Overall length 9850 MM Overall width 2500 MM Overall height 3500 MM Weight kg Dead weight 14600 KG Rated Loading Capacity 13900 KG Gross vehicle weight(GVW) 28500 KG Front axle loading capacity 7500 KG Rear axle loading capacity 21000 KG Max compression force (kg) >35000
