• Model NO.：CLW-suction620
• Condition：New
• Transport Package：Nude
• Specification：10010*2500*3150mm
• Trademark：Evangel
• Origin：China
• Production Capacity：1000,Year

Euro 4 340HP Engine SinoTruk Suction Type Sewer Scanvenger Jet Vacuum Truckstechnical parameter of chassisChassis Model /ManufacturerOptional with air-condition cab Flating roof (White)Overall Dimension10000×2500×3600mmTotal Mass31000KgRated Payload16710KgKerb Weight14160Kgfront overhang/rear overhang962/1576EngineModel/Rated PowerMC07.340-50/ 340HPSinotruk Motor Co., Ltd. Emission StandardEuro 4 or Euro 5Type & Size of Tyre11.00R20driving type 6×4Wheel Base4300+1350Number of leaf spring of suspension5/8+4Max Speed90Volume of tank 20.4m3Thickness of tank5mm /6mmModel of vacuum pumpAbsolute working pressure: 400PaAcademic suction speed: 45L/sRotation speed: 500rpm

Vacuum pump is drived by PTO, to self-suck

and self-discharge by four-way valve. this truck can suck the mud,

sewage, dejection and the dirty water with small stone under by vacuum pump
