• Model NO.：HK37
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Operation Weight (Kg)：25ton
• Color：Yellow
• Weight：30ton
• L*W*H：8593*3050*3435
• Transport Package：Suitable Package for Shipment
• Specification：CE Certificate, ISO
• Trademark：EVANGEL
• Origin：China
• Production Capacity：15 Sets, Month

ItemUnitJBT30Pumping systemTheoretic outputm³/h30Theoretic outlet pressureMpa8Theoretic delivery heightm130Theoretic delivery distancem320Pumping frequencytimes/min15Distribution valve type S pipe valveConcrete cylinder spec.
(inner dia. x stroke)mmΦ180×1000Oil cylinder spec.
(outer dia. x inner dia. x stroke)mmΦ100×Φ70×1000Outlet diametermmΦ150Delivery pipe inner diametermmΦ125Hopper volumeL450Rated voltageV~380Main motor powerKw30Vibrating motor powerKw0.04Hydraulic circuit type openMain system max. oil pressureMPa22Distributing system oil pressureMPa16Mixing system oil pressureMPa9Max. Mixing speedr/min24Oil tank volumeL120Max. aggregate diametermm≤30Concrete slump scopemm80~200Outer dimension (L*W*H)mm4370×2100×2580WeightKg3300Mixing systemMixing volume per timem³/time0.4Mixing volume per hourm³/h16Mixing motor powerKw3×2=6Lifting motor powerKw4.5Water pump powerKw0.55Vibrating motor powerKw0.55HB37A 37m concrete mixer truck hydraulic pump

1.Reach height:37.4m
2.Engine model:6WF1
3.Max.speed:90KM/H
No.
Item
Unit
Parameter
1
Max. speed
km
90
2
Min. turning diameter
m
18.4
3
Brake distance
m
7
4
Approach angle
°
31
5
Departure angle
°
12
6
Chassis model

CXZ51Q ( Japan )
7
Total weight
kg
28150
8
1st axle load
kg
6780
9
2nd, 3rd axle load
kg
21220
10
Engine model

6WF1
11
Max. Engine power
kW
287
12
Max. Engine torque
N.m
1862
13
Max. grade-ability
%
38
14
Fuel consumption limit
L/100km
34
15
Outline dimensions (Length´ Width ´Height)
mm
11990´2490´3900

Technical Data for Pumping Operation

No.
Item
Unit
Parameter
1
Theoretical output
m3/h
138/90
2
Max. delivery pressure
MPa
8.7/13
3
Reach height
m
37.4
4
Reach depth
m
23.7
5
Front outrigger transverse span
mm
7280
6
Rear outrigger transverse span
mm
6600
7
Outrigger longitudinal span
mm
6860
8
Delivery pipe diameter
mm
125
9
Remote control distance
m
100
10
Placing boom slewing range
°
370Contact
