• Model NO.：JBC-35
• Power(W)：85kw
• Weight：7200 Kg
• Warranty：1 Year
• Concrete Output：14cbm,H
• Engine：Yuchai4105
• Transport Package：40hc
• Specification：7830*2680*4170 mm
• Trademark：SDJK
• Origin：Shandong
• HS Code：8705400000
• Production Capacity：500sets,Month

Model

JBC-35

Mixing Drum

 Mixing Capacity

3.5 m³

 Geometrical Capacity

5.3 m³

 Concrete Output

3.5 m³ / batch, 14 m³ / h

 Drum Rotating Speed

16-20 rpm

 Drum Rotating Angle

270°

Engine

 Model

YUCHAI 4105

 Type

4-cylinder, 4-stroke, turbo-supercharged,water-cooling

 Rated Power

85 KW (116HP) @ 2400 rpm

 Emission Standard

Euro II

Loading Bucket & Discharge Chute

 Loading Bucket Capacity

0.6 m³

 Loading Times to Full Drum

6 Times

 Discharge chute

2 Sets

With Extender

Rotate 90°

Water System

 Max. Water suction Volume

550 L/min. (self-priming hydraulic water pump)

 Water tank Volume

2x310 L

Mixer

 Max. Travel Speed

30 km/h

 Gradeability

40°

 Min. Turning Radius

5300 mm

 Operating Weight

7200 kg

 Max. Load

8400 kg

 Max. Gross Weight

15600 kg

 Overall Dimension (L×W×H)

7830*2680*4170 mm

 Fuel Tank Volume

75 L

 Total Hydraulic System Capacity

75 L

 Oil Tank Volume

16 L
