• Model NO.：DFL1120B
• Horsepower：150-250hp
• Fuel：Diesel
• Bearing Capacity：Medium
• Car Type：Van
• Condition：New
• Chassis Brand：Dongfeng, Kingrun
• Cabin：Half Row, Rhd or LHD
• Engine：125kw , 170HP Cummins
• Gear Box：6 Forward Gears & 1 Reverse
• Truck Max Payload：8t ~ 10t
• Drive Axle：9t
• Cargo Body Size：6100*2260*2300mm
• Crago Body Volume：25 Cubic, 30cubic
• Refrigeration Systems：Thermo King Non-Independent Refrigeration Unit
• Temperature Range：-18 Degree
• Transport Package：After Waxing by Container, RO-RO, Bulk Freighter
• Specification：ISO&CCC
• Trademark：SUNY
• Origin：Hubei Suizhou
• Production Capacity：500 Unit , Month

 Products Technical SpecificationProduct Name 4*2 Refrigerator TruckBrand-SeriesDongfengChassis Model    DFL1120B Emission StandardEuro 3Fuel typeDieselCabin Half row,with A/CWhole vehicle
main dimensions (mm)




 Overall dimensions (L×W×H) 8700*2500*3850Crago body dimensions  6100*2260*2300Wheel base       4700Front overhang       1430Rear  overhang    2360Min. ground clearance 500Weight data (kg)

 G.V.W12495Curb weight (chassis)6300Max payload8000-12000Whole vehicle
main performanceMax. speed (km/h)90 Max. slope of climb (%)30Engine



 ModelB170 33Rated power (kw/rpm)125kw / 2500Displacement (L)5.9Number of cylinders6Max torque (N.m/rpm) / 1500TransmissionNumber of gears6 forward gears & 1 reverseRear axlecapcaity9tons axleSuspensionLeaf spring7/9+6,8/10+8Steering Wheelleft/right hand driveLHDBrake systemService brake Air brakingElectric deviceRated voltage24VTyres & Quantity9.00-20 & 6+1Cargo body DescriptionCargo body dimensions  (mm)6100*2260*2300Cargo body materialFRP inside & outside of the van,
polyurethane as the insulationCargo body thickness80 mm Optional 100mmBack Doorhinged doorSide door Optional                                 hooksequipmentRefrigeration systemsEquipped with KV-300
Thermo King Brand                                 Temperature RangeNormal temperature,refrigeration temperature reached -18°COthersStainless Steel door frame,Stainless steel corrugated floor,
Mark lamp at the four (4) corners f the body
,Room lamp will be provided inside the cabin.
We also have Dongfeng  water tank truck,Oil tank truck,Garbage truck,Van truck,Flatbed Truck,Dump truck,Truck with crane,etc

Other brand of Chassis eg,Dongfeng-DFAC,FOTON-AUMAN-FORLAND,FAW-J5-J6,SHACMAN-F3000-M3000-X3000,SIONTRUK-HOWO-A7,Beiben,IVECO-HONGYAN-GENLYON,JAC,JMC,YUEJIN,KAMA,T-KING,UD,HINO,etc.

Product Series:
1.  Fuel tank truck/trailer/semi-trailer/container.
2.  Water tank truck/trailer/semi-trailer/container.
3.  Chemical tank truck/trailer/semi-trailer/container.
4.  Bitumen tank truck/trailer/semi-trailer/container.
5.  Bulk powder tank truck/trailer/semi-trailer/container.
6.  Gas tank truck/trailer/semi-trailer/container.
7.  Dump truck/trailer/semi-trailer
8.  Truck mounted crane
9.  Fecal suction truck.
10. Sewage suction vacuum tank truck.
11. High pressure washing truck.
12. Sewage suction vacuum tank and high pressure washing truck.
13. (vacuum)Sweeper truck.
14. Garbage truck(swing arm type,sealed dump type,compression type,hanging barrel type,docking type)
15. Concrete mixer truck
16. Fire truck
17. Wrecker
18. Refrigerator truck/trailer/semi-trailer
19. Platform transported truck/trailer/semi-trailer
20. Van truck/trailer/semi-trailer
21. High-altitude operation truck
Packaging & Shipping
Truck is nude packing, shipping by container, bulk cargo, ro-ro.
We will choose the best shipping type basis on truck volume, truck structure, Sail Schedule, clients' requirement for clients!

Customer service
We supply sincerity, efficient, professional, happiness service on pre-sale, in the sale, after-sale
Any requiry will be replied within 24 hours.
High quality ,competitive&reasonable price, fast lead time.
Our products are direct from factory,there is no middle man,no high markup,so we can provide        quality items yet very competitive price.
We guarantee that all our goods has gone through strict quality control and testing to ensure that it is in good condition before ship out.We strive for 100% customer satisfaction on every sale we complete.
Fast delivery time: within about 10~~20 working days.
We provide 13 months warranty.
We supply quick-wear parts and  spare parts in time for customer .
