• Model NO.：Vacuum Road Sweeper
• Fuel：Diesel
• Payload：6 Cbm Garbage +7 Cbm Water
• Use：Burnishing
• Cleaning Process：Cold Water Cleaning
• Condition：New
• Tire：900r20, 6 Pieces with 1 Spare Tire.
• Engine：I.S.U.Z.U
• transmission：6~9-Speed, Single, Dry
• Transport Package：Nil
• Specification：m ilitary standard.
• Trademark：I. S. U. Z. U
• Origin：China
• HS Code：8705909990
• Production Capacity：10000

I SUZU Road Cleaning sweeper truck(6 cbm garbage +7 cbm water)

Item No.

Parameters

Overall Dimension

8800*2400*3000 mm

Drive model

4x2, new condition , LHD

Gross weight

14450 kg

Curb Weight

8845kg

Wheel Base

5200mm

Front/rear Overhang

1150/2050mm

Front/rear Tread

1745/1620 mm

Approach/Departure Angle

21/12 degree



Engine

I.S.U.Z.U ENGINE, 4HK1-TC, Diesel Engine, Four Stroke,

4 Cylinder in line.

Engine horsepower

190HP , 139 kw, Euro 4

Displacement

5.193 L(Diesel)

Max Driving Speed

90 km/h

Gear Box

I SUZU MLD brand ,6 Forward Gear, 1 Backward Gear

Tire

900R20, 6 pieces with 1 spare tire.

Upper part of the road sweeper truck







Tank



Garbage tank

Tank material

Stainless steel 304 3mm

Tank volume(cbm)

6 cbm



Water tank

Tank material

Stainless steel 304 3 mm

Tank volume(cbm)

7 cbm



Auxiliary engine

Model

JMC Brand

Power(kw)

64 kw, 87 HP

Motor

Brand

Imported brand motor

Switch

Brand

Imported French S chneider brand switch

High pressure

pump/Low pressure pump



Brand

Imported Germany brand-For high pressure pump; China weilong brand --low pressure pump



Brush

Quantity(pic)

2 pics

Sweeping and cleaning width

3 meters



Operation detail

Sweeper Working speed

3-15 km/h

Cleaning working speed

15-20 km/h











Dust system

Model

Low pressure misty

Dust by sweeper

Left and Right side front brushing.

Dust by sucking

Sucker included in the sucking hole.

Control system

Electrical control, controlled easily.



Main part

Germany imported high pressure Pump, water filter, pipes, stainless steel spraying structure, high pressure

spraying head and so on.













Hydraulic system

Type/model

Open type, electrical control operation.



Main parts

Gear pump, engine motor, hydraulic cylinders,electromagnetic valve, integrated part, high

pressure pump and so on.

Motor

Japan Sanyo

Earthquake proof-Pressure

gauge

Germany IMT

Volume of the hydraulic oil

>60 L

Pressure of system overflow

10-12













Electrical system

Voltage of truck chassis

system

24 v

Voltage of operation

12 v



Electrical control system

Auxiliary engine speed gauge, auxiliary water

temperature gauge, machine oil temperature alarm, operation control switch and so on.

Controller

Japan brand

Control switch

S chneider brand switch

Breaker

Germany hagrid

Cleaning system

Main part

Sweeper structure, brush, oil cylinder, oil pipe, linking

  bolts, adjusting bolts, hydraulic motor etc.Diameter of brushing800-900 mm.Speed of brushing motor140 r/min.Scrolling number2 pics.Number of each scrolling22Sloping angle of brushing systemFront side:5-15°; Extend side: 5-10°









Sucker system

Sucking diameter110mmSucker brandGerman brand NORRESWalking wheel bearingsSwedish SKF brandGround distance5-8 mmSpeed of sucker50-65 mmPressure of sucker380 mm H2O







Fan system

ModelHigh pressure fans.Rated working speed2700 r/minDrive modelAuxiliary engine, clutch and drive belts.Flow meters5000-7800 m3/h.







Remarks

1, With water sprayer-bar 2, Rear vacuum cleaner 3, Blower

4, Rear LED pilot lamp

5, Self unloading box body

6, The color will be designed on basis of your requirements.

7. Power system: DC 24V

Compared with common road sweeper, this model has more functions:Road sweeping, road flushing, multi-angle slush flushing, separation zone cleaning, freeway guard rail flushing,spraying, moistening and dust containing, high pressure water gun for car cleaning/low flat flushing with strong water flow, road sprinkling and flower watering from both sides and so on.
1.The Vice-engine sweepers no. Fans and other work devices to take power through the chassis engine to drive.
2. Cleaning device with Automatic Collision Avoidance Obstacle protection and automatic reset function (by national patent)
3. "Mid four brush - rear nozzle" structure layout with sweeping wide, clean and efficient features, and facilitate the cleaning device and nozzle adjustment and maintenance.
4.Pneumatic conveying system with digestion and absorption of foreign advanced technology and efficient sweepers dedicated fans and can auto-leveling with the road the whole floating nozzle.
5.Sweeper combined with trochar disc, it can work excellently and can automotically choose work type according to waste condition on the ground and speed of the truck. ;
6.Trash and water tank large, continuous cleaning operation a long time.
7. Left, right front linkage scan can work independently or can choose to use the right front or left front sweep sweep to work independently.
8.Hydraulic system with superimposed solenoid hydraulic valve, highly integrated, reliable, easy maintenance;
9. Control switch installed in the driver focused interior, all electronic control can be found in cab ,Beautiful appearance designed via computer.
