• Model NO.：CLW5250TQZZ
• Brand：Sinotruk
• Condition：New
• Horsepower：251 - 380HP
• Engine Capacity：> 8L
• Drive Wheel：8X4
• Front Axle：Hf9
• Rear Axle：Hc16
• Tyre：12.00r20 Radial Tyres
• Color：Red, Blue, Yellow, Green, White
• Transport Package：Nude Package with Wax
• Specification：8214x2496x3450mm
• Trademark：Sinotruk
• Origin：Shandong, China
• Production Capacity：20000 Units Per Month

ModelCLW5250TQZZ Chassis modelZZ1257N5847CDriving form6x4Total mass(kg)25000Curb weight(kg)17500Engine

WD615.47(371HP), Euro II emission standard

Engine type: Diesel 4stroke direct injection engine,

6cylinder inline with water cooling, turbo-charging & inter cooling

Cab

HW76(one bed with A/C)

TransmissionHW19710(10 Forward, 2 Revise)Front axleHF9 (9000kg)Driving axleHC16 (16000kg x 2)Steering systemZF8098Tire12.00R20 (11pcs, including one spare tire)Wheelbase(mm)5825+1350front/rear Overhang (mm)1500/1885Approach/departure angle(°) 16/10Maximum speed(km/h)90Number of spring leaf 10/12Max lifting capacity(kg)

16000

Max lifting high(mm) 9800Lift-hoist telescope length(mm) 3000Winch rating pulling capacity(kg) 5000*2Length of steel(m) 45Max under-hoist useful length(mm) 2880Rating under-hoisting capacity(kg) 4990Fully extended max under-hoisting capacity(kg) 3850Rating under-pulling capacity(kg) 25000



What can we do for customer:

1, Satisfied products with international standard;

2, Full aspect service from order to shipping;

3, Most suitable advice when customer has special needs;

4, Find a better shipping and lower the cost of shipping.
