• Model NO.：CLW
• Bearing Capacity：Large
• Car Type：Van
• Condition：New
• Truck：Refrigerator Truck
• Refrigerated Temperature(°)：-15
• Driving Type：LHD and Rhd
• Refrigarator Brand：USA Thermo King,Korean Kaili,Hanya Mini Refrigerat
• Van Box Material：Fiber Steel,Stainless Steel
• Refrigerator Truck Door：Rear Door and Side Door
• Drive Mode：4*2
• Thickness of Insulating Layer(mm)：80-100mm
• Filling Medium：Fresh Meat, Fruit, Vegetable Fish, Ice Cream
• Market：Global
• Transport Package：Naked, Waxing and So on
• Specification：Polyurethane
• Trademark：CLW
• Origin：Hubei. China
• Production Capacity：800sets,Month

Cabin

Driving type 4x2

With three seats, With air conditioner, Left hand driven.

Vehicle Main Dimensions

Overall dimensions (L x W x H)mm

8700×2490×3850

Wheel base  (mm)

4500

Wheel track  (front/rear) (mm)

1506/1466

Approach/Departure angle(°)

19/15

Weight in KGS

Tare Weight

Loading Capacity

Front axles loading capacity

5000

Rear axles loading capacity

10000

Max. driving speed(km/h)

90

Brand

YUChai

Model

YC4E160-33

Type

4-stroke direct injection , 4-cylinder in-line with water cooling

Horse Power(HP)

160HP

Emission standard

Euro 2

Gearbox

Manual type, 5 Forwards & 1 Reverse

Steering Gear

Power steering

Tire

7.00-16 with one spare tire , 7 pieces

Brake System

Service brake: dual circuit compressed air brake

Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Refrigerator Van

Refrigerator Van body

Dimensions(mm)

6100*1910*1900 mm

Van material

Glass fiber reinforced plastic

Insulating layer material

Polyurethane foam

Insulating layer thickness(mm)

80 mm

Self Contained Cooling Unit

Brand

American brand Carrier

Model

VIENT0350

Refrigerated Temperature(°)

-18ºC-0ºC

1. Our factory is a professional truck & tanker manufacturer with more than 12 years experience in China.

2. There are totally 8000 workers, include 100 senior welder and 15 senior engineers.

3. More than 300 type of products supply.

4. Our sales volume of 2015 reach US$300 million.

1. One year quality warranty for key parts such as axles, engine, transmission;

2. All spare parts would be OEM and supplied at cost prices;
3. Overseas service center to ensure efficiency after-sales service;
4. Regular after-sales visit to collect information about the vehicle's working status and feedback from customers.


Packing and Shipping


Other Products


1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

Customised Truck & Trailer Solutions to Meet Your Requirements
