Large Fire Disaster Fighting Vehicle Zoomlion 5313jp25

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • Type：Aerial
  • Certification：ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
  • Volume：＜3000L
  • Emission Standard：Euro 2
  • Transmission Type：Manual
  • Payload：20T

Base Info

  • Model NO.：5313JP25
  • Fuel：Diesel
  • Drive Wheel：4×2
  • Horsepower：＜150hp
  • Condition：New
  • Max Speed：90 Km,H
  • Fuel Tank Volume：300 L
  • Wheel Base：4600+1400mm
  • Max Working Height：25m
  • Max. Working Outreach：14.8m
  • Engine Power/Gvw：10.5kw,T
  • Fire Monitor Model：Akron3482+5177
  • Max. Flowing of Fire Monitor：4800L,Min
  • Transport Package：Cartons
  • Specification：11500× 2500× 3970
  • Trademark：zoomlion
  • Origin：China
  • HS Code：8429521200
  • Production Capacity：10000 Units,Month

Description

Brief CodeJP25ChassisSino-Trunk ZZ5357TXFV464ME1Engine power(kW)327Max. torque(Nm)2100Cab Seats2Max speed(km/h)90Fuel tank volume(L)300Wheel base(mm)4600+1400FuelDieselMax working height(m)25Max. working outreach(m)14.8Engine power/GVW(Kw/t)10.5Fire monitor modelAKRON3482+5177Max. flowing of fire monitor(L/min)4800Max. spraying reach of fire monitor(m)≥80GVW(kg)30600Water tank volume(L)8000Foam tank volume(L)2000Water pump modelRSD100Max. flowing of water pump(L/min@MPa)6000@1.03Overall dimensions(mm)10070×2500×3770Boom sections3Boom operating time(s)<90
Product Show
Large Fire Disaster Fighting Vehicle Zoomlion 5313jp25
Large Fire Disaster Fighting Vehicle Zoomlion 5313jp25
Large Fire Disaster Fighting Vehicle Zoomlion 5313jp25
