Dongfeng EQ5090g 4X4 5000L Water Tanker
Shiyan Tuosheng Industry & Trade Co., Ltd.- After-sales Service：12 Months
- Warranty：12 Months
- Volume：＜5000L
- Certification：ISO9000, CCC, TS16949
- Emission Standard：Euro 3
- Transmission Type：Manual
Base Info
- Model NO.：EQ5090G
- Payload：5t
- Fuel：Diesel
- Drive Wheel：4X4
- Engine Capacity：4 - 6L
- Condition：New
- Transport Package：Nude
- Specification：5CBM
- Trademark：DONGFENG
- Origin：Shiyan City, Hubei Province, China
- HS Code：8705909090
- Production Capacity：200 Units,Month
Description
Basic Info.
Model NO. EQ5090G Payload 5t Fuel Diesel Drive Wheel 4X4 Engine Capacity 4 - 6L Condition New Transport Package Nude Specification 5CBM Trademark DONGFENG Origin Shiyan City, Hubei Province, China HS Code 8705909090 Production Capacity 200 Units/MonthProduct Description
Dongfeng EQ5090G 4x4 5000L Water Tanker| Overall dimension(mm) | 6500x2470x2700mm (up to cabin roof) |
| Tank details (mm) | 5000L, with SUS 304, thickness with 3.5mm |
| Wheelbase(mm) | 3600 |
| Wheel track(Front/Rear)(mm) | 1876/1870 |
| Approach/Departure angle(o) | 35/33 |
| Curb weight (kg) | 5200 |
| Chassis max allowed load weight | 7910kg |
| Rated power(kW/r/min) | 128/2200 |
| Max torque(N·m/r/min) | 590/1200 |
| Displacement(L) | 5.9 |
| Max speed(km/h) | 85 |
| Max grade ability(% ) | 60 |
| Slope parking angle(%) | 40 |
| Min. ground clearance(mm) | 305(axle housing bottom) |
| Min. turning radius(m) | ≤8 |
| Fuel tank volume(L) | 160+80 |
| Maximum driving range(km) | ≥600 |
