Rhd Dongfeng Concrete Mixer Truck

Henan Tarzan Industrial Co., Ltd.
  • Certification：ISO9000
  • Transmission Type：Manual
  • Emission Standard：Euro 3
  • Displacement：9
  • Payload：10 Cbm
  • Fuel：Diesel

Base Info

  • Model NO.：DFD5250GJBA
  • Drive Mode：6x4
  • Maximum Horsepower：300-400hp
  • Condition：New
  • Product Name：Rhd Dongfeng Concrete Mixer Truck
  • Engine Model：Isle 340 III
  • Engine Type：6-Cylinder in Line, Electric Control
  • Max. Power(Kw/Rpm)：250,2200
  • Max. Torque(N.M/Rpm)：1350,1400
  • Cab：D310g
  • Gearbox Model：9js150t-B
  • Clutch：430mm, Diaphram Spring Clutch
  • Frame：300*(8+8)
  • Frame Dimension：Frame Width 940 (Front ), Frame Width 810 ( Rear )
  • Tyre Size：11.00-R20
  • Wheelbase：3800+1350mm
  • Front/Rear Tread(mm)：1986,1860
  • Appr./Depa. Angle：30,18
  • Mixing Capacity：10 M3
  • Transport Package：Nude Packing.
  • Specification：9700*2500*3990mm
  • Trademark：Dongfeng
  • Origin：Hubei, China
  • HS Code：8705400000
  • Production Capacity：10 Cbm

Description

Air braking system + ABS, Hydrulic power steering, 350L full steel fuel tank.Rhd Dongfeng Concrete Mixer TruckRhd Dongfeng Concrete Mixer TruckRhd Dongfeng Concrete Mixer Truck
