Steel Pipe Fabrication Light Rail Conveying System
Henan Perfect Handling Equipment Co., Ltd.- Certification：CE
- Product Name：Pipe Conveying System
- Usage：Heavy Duty Material Transportation
- Application：Steel Industry, Factory, Warehouse, Port
- Brand：Perfect
- Load Capacity：1-300 Ton
Base Info
- Model NO.：BDG
- Special Function：Anti-Explosion, Heat-Resistant, Lifting, Dumpling
- Control Mode：Pendant,Remote,PLC Control
- Power Mode：Battery
- Color：Customzied
- Material：Steel
- Transport Package：The Whole Cart Will Be Packed by Tarp.
- Specification：Customized
- Trademark：PERFECT
- Origin：Xinxiang
- HS Code：84289090
- Production Capacity：50 Sets,Month
Description
Recommended Rail ModelP15 P24 P43 QU100 QU100
6. Power supply mode of pipe rail conveying system
The motorized material handling equipment manufactured by Henan PERFECT Handling Company can be designed with different power supply mode, which include storage battery, cable, conductive rails, and so on. According to customers' different application environment, we would recommend the best suitable transfer solution with different power supply mode:
Storage Battery Powered Transfer carts: This kind motorized transfer carts powered by battery is suitable for long running distance, low using frequency, "S" "L" and curved tracks, anti-explosion and ferry occasion.
Cable reel powered transfer cart on rails: This kind electric flat transfer carts powered by cable is most used in occasion with high using frequency, short running distance, straight direction route.
Conductive track powered motorized transport trolleys: This kind material automated transport trolleys get power from the conductive tracks installed on the floor. These transport trolleys are suitable for high using frequency and large loading capacity. It has strict requirements about the track installation which need to be insulated.
Steerable transfer carts: These steerable transfer carts apply to multidirectional heavy duty transportation on cement floor and steel plate with rotation required. They can turn freely in 360°degree to change the moving direction. So they are powered by battery which won't be affected by the trailing cable during running in small or limited space.
7. Our Factory and Customers' visit
8. Q&A
What Are The Advantages of Using a Transfer Cart?
For smaller loads, manual carts can be dedicated to specific work place activities such as shuttling materials. This often makes the carts more available for use. Transfer carts are more accommodating for moving long loads through restrictive passage ways or doorways. For heavier loads transfer carts are an excellent affordable choice for their ability to handle heavy loads. Transfer carts are compact in design and work well in areas with limited floor area. Another advantage over lift trucks is how the cart deck can be customized to suit specific loads.
What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)
How can Transfer Carts be customized?
Please tell us:
What load or product will be transferred onto the cart?
What is the weight of the heaviest lift or load?
What are the dimensions? (Length; Width ; Height)
What is the trip time and frequency? (# of Trips per , Shifts per day:)
What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
What is the distance to travel?
Other relevant information or using condition.
