• Model NO.：QHQ5080JGK
• Condition：New
• Transport Package：Nude
• Specification：L*W*H 7650*2250*3450
• Trademark：WUXIAO HAIKIN
• Origin：China

Basic Info.

Model NO. QHQ5080JGK Condition New Transport Package Nude Specification L*W*H 7650*2250*3450 Trademark WUXIAO HAIKIN Origin China

Product Description

1, Main configuration

Name	Model and description
chassis	jiefang brand  CA1080P40K59L3BE6A84 (National VI)
Engine	WP3NQ160E61
Cab	Single row, 3 passengers allowed
Force taking system	Power take-off from gearbox
Work platform	1600*800*1100,Rated load 200 kg
cantilever crane	High strength steel, four expansion arms
turning gear	Top mounted 360 ° hydraulic drive rotation, platform rotation ± 90 °
operating system	The turntable and working platform are equipped with electronic control operation, the turntable is equipped with emergency manual operation, and the control screen displays and monitors
Hydraulic system	Electro hydraulic proportional control, stepless speed regulation, electric emergency pump
Leveling system	Automatic leveling system of equal volume oil cylinder
Pipeline transportation	Drag chain protection system

2.Main operation technical reference

Maximum working height of platform	23m
Maximum operating range of platform	14m
Rated load of platform	200kg
Rotation angle of turntable	360°
Rotation angle of working platform	About 90 degrees.
Operating range at maximum operating height of working bucket	4.5m
The maximum operating height is the maximum operating range of the working bucket	2.5m

3.Main features:
>Adopt electro-hydraulic proportional valve to control the action of the arm
>Working bucket electric swing mechanism, can make the working bucket 90 degrees left 90 degrees right swing;
>Computer controlled automatic limiting, automatic monitoring of the whole process of the working status, automatic limit of the operating radius;
>Vertical legs and working arms are interlocked
>Anti collision function of working arm with cab and outrigger
>Automatic interlock on and off, prevent wrong operation, safe and reliable
>Equipped with electric emergency power source to effectively deal with sudden failure
>Automatic accelerator system;
