• Model NO.：HHZ5310GJBHJBJB
• Maximum Horsepower：300-400hp
• Condition：New
• Rated Weight：13470kgs
• Axles′ Quantity：4PCS
• Axle Base：1800+3450+1350mm
• Tyre Quantity：12PCS
• Chassis：Bj5313gmfjc-S
• Overall Length：1090011500mm
• Overall Wide：2500mm
• Overall Height：3895,3995mm
• Maximum Speed：77km,H
• Transport Package：in Nude
• Specification：CCC ISO9001 SGS
• Trademark：CHHGC
• Origin：China
• HS Code：8705400000
• Production Capacity：5000 PCS Per Month

                                                                         Main Technical Parameter  Item No.HHZ5310GJBHJBJBBatch254   BrandCHHGCTypeConcrete mixer truck   Rated weight13470Total Weight(kg)30995   Curb weight(kg)17330Fuel TypeDiesel oil   Emission standardGB17691-2005 GBIII,GB3847-2005Axles' Quantity4   Axle base(mm)1800+3450+1350Axle load6610/6610/17775(2 axles installed side by side)   Q'ty of the steel plate spring13/14/12Tyre Quantity12   Tyre size12.00-20 16PR,12.00R20 16PR,11.00-20,11.00R20,Approach/Departure angle18/20,18/18   Front/rear suspension(mm)1532/2768,1532/3368Front wheel base(mm)2005/2005   Back wheel base(mm)1865/1865ChassisBJ5313GMFJC-S   Overall length1090011500Overall wide2500   Overall height3895/3995Maximum speed77   Cab capacity 3    Products' TypesConfiguration for the Concrete Mixer semi-trailerReduction gearsPumpThe motorBrandTypeBrandTypeBrandType9 CBM concrete mixer truckStandard configurationZFP4300Sauer-danfoss T90PV075SauerT90MF75Option 1PMPPMB6.5SPSauer-danfoss T90PV075SauerT90MF75Option 2Shaanxi cuhkTOP P68Shaanxi cuhkARK PV089Shaanxi cuhkARK MF089Option 3ZFCML8(entirety type)Sauer-danfoss T90PV075____10 CBM concrete mixer truckStandard configurationZFP5300Sauer-danfossSPV089SauerTMM089Option 1ZFP4300Sauer-danfoss T90PV075Sauer-danfossT90MF75Option 2Sauer-danfossPMG61.2Sauer-danfossSPV089Sauer-danfossTMM089Option 3PMPPMB6.5SPSauer-danfossSPV089Sauer-danfossTMM089Option 4Shaanxi cuhkTOP P68Shaanxi cuhkARK PV089Shaanxi cuhkARK MF089Option 5ZFCML8(entirety type)Sauer-danfossT90PV100____12 CBM concrete mixer truckStandard configurationZFP5300Sauer-danfossT90PV100Sauer-danfossT90MF100Option 1ZFP5300Sauer-danfossSPV089Sauer-danfossTMM089Option 2Sauer-danfossPMG71.2Sauer-danfossT90PV100Sauer-danfossT90MF100Option 3PMPPMB7.1SPSauer-danfossT90PV100Sauer-danfossT90MF100Option 4Shaanxi cuhkTOP P75RShaanxi cuhkARK PV089Shaanxi cuhkARK MF089Option 5ZFCML10(entirety type)Sauer-danfossT90PV100____14 CBM concrete mixer truckStandard configurationSauer-danfossPMG71.2Sauer-danfossT90PV100Sauer-danfossT90MF100Option 1PMPPMB7.8SPSauer-danfossT90PV100Sauer-danfossT90MF100Option 2Shaanxi cuhkTOP P90Shaanxi cuhkARK PV090AShaanxi cuhkARK MF090A16 CBM concrete mixer truckStandard configurationPMPPMB7.8SPSauer-danfossT90PV100Sauer-danfossT90MF100Option 1Shaanxi cuhkTOP P90Shaanxi cuhkARK PV090AShaanxi cuhkARK MF090A*Company profile

Henan Haiheng Import and Export Co., Ltd has been Established in 2004.We have our producing  factory in henan.We are able to supply Semi-trailers(Stake semi-trailer train, Skeletal container trailer, Flatbed container semi trailer, Terminal trailer, Semi-trailer with side wall, Stake semi-trailer, Stake semi-trailer with goose neck, Stake semi-trailer with long/short locks, special semi-trailer for carrying coal, Curtain type semi-trailer), tank trailer series(Concrete mixer, Bulk grain semi-trailer, Bulk cement truck, Bulk cement semi-trailer, Chemical liquid semi trailer, oil tank semi-trailer with heating heating device, stainless fuel tank semi-trailer Aluminum fuel tank semi-trailer, Oil transport trailer train), dump truck series, Special purpose semi-trailer(Stake tipper trailer, side dumping semi trailer, Front-mounted dumping semi trailer, Tipper semi-trailer with front mounted cylinder, Coiled sheet transportation semi trailer, farm tractor with farm implements.

---Factory Show






*FAQ

1. Can i have samples of this type of trailer to test the quality?

Yes, you can buy any samples to test the quality,our MOQ is 1 set.


2. What's the delivery time and can you lower the price?

It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.


3. Can i customize the painting and the trailer design?

Yes, we offer customized design and logo for reasonable type.


4. What's the payment method?

TT 30% as Deposit, Balance Before shipment by TT or L/C at sight.
