• Model NO.：SUNTAE-S01
• Width：Customized
• Sweeping Area：Customized
• Transport Package：by Container
• Trademark：SUNTAE
• Origin：Shandong

Basic Info.

Model NO. SUNTAE-S01 Width Customized Sweeping Area Customized Transport Package by Container Trademark SUNTAE Origin Shandong

Product Description

SUNTAE-S01  Electric Cargo Box   Lead Acid/Lithium Battery Available

First of all, it's an electric car, lead-acid / lithium battery can, small size, flexible operation, easy to use.Secondly, the pure electric vehicle uses electric motor instead of fuel engine, which is driven by motor without automatic transmission. Compared with the automatic transmission, the motor has simple structure, mature technology and reliable operation.

characteristic
1.The maximum power of the internal combustion engine can be determined according to the average power required after the hybrid power is adopted. At this time, the engine works under the optimal conditions of low fuel consumption and less pollution. When the power of high-power internal combustion engine is insufficient, it is supplemented by the battery; when the load is small, the surplus power can generate electricity to charge the battery. Because the internal combustion engine can work continuously and the battery can be continuously charged, its travel is the same as that of ordinary cars.
2.Because of the battery, it is very convenient to recover the energy when braking, downhill and idling.
3.In the downtown area, the internal combustion engine can be shut down and driven by the battery alone to achieve "zero" emission.
4.With the internal combustion engine, it is very convenient to solve the problems encountered by pure electric vehicles such as air conditioning, heating, defrosting and so on.
5.We can use the existing gas stations to refuel, and we don't need to invest any more.
6.It can keep the battery in good working condition without overcharge and over discharge, prolong its service life and reduce its cost.

Parameter details

Energy type	Pure electric
Number of seats	2
Number of doors	3
Length (mm)	2488
Width (mm)	1506
Height (mm)	1670
Wheelbase (mm)	1600
Total motor power (kw)	29
Motor layout	Front
Transmission type	Fixed ratio gearbox
Driving mode	Front drive
Slow charging time (hours)	13.5
Battery energy (KWH)	28
Pure electric range of MIIT (km)	305
Vehicle mass (kg)	849
Minimum ground clearance (mm)	130
Front track width (mm)	1310
Rear track width (mm)	1320
Maximum speed (km / h)	100


2. Please send your usage background to get technical consultation from our technical department.

Please see videos of test and application at our motor branch
EIFPMG youtube channel https://electric-car.en.made-in-china.com
What we will do for you:
1. provide technical consultant before order and confirm your actual technical requirement according to your description on usage within 1-3 working days;
2. supply the right and approved under serious quality inspection system within 10 days(if customized model,we will recheck the delivery time);
3. provide technical support when the product arrives you, to make sure you can run it smoothly in actual field;
4. provide 1 year warranty, and whole life technical support;
5. always update our product information with you.

Welcome to Visit us for Further Talking on Strategy Cooperation on any EV related projects:


Equipment features
No pollution, low noise
The exhaust gas produced by electric vehicle without internal combustion engine is very beneficial to environmental protection and air cleaning, which is almost "zero pollution". It is well known that CO, HC and NOx, particulates, odor and other pollutants in the exhaust gas of internal combustion engine vehicles form acid rain, acid fog and photochemical smog. There is no noise produced by internal combustion engine in electric vehicle, and the noise of motor is smaller than that of internal combustion engine. Noise is harmful to human hearing, nerve, cardiovascular, digestive, endocrine and immune system.
High energy efficiency and diversification
The research of electric vehicle shows that its energy efficiency has exceeded that of gasoline engine vehicle. Especially in the city operation, the car stop and go, driving speed is not high, electric vehicle is more suitable. When the electric vehicle stops, it does not consume electricity. In the braking process, the motor can be automatically transformed into a generator to realize the energy reuse when braking and deceleration. Some studies have shown that the energy efficiency of the same crude oil after crude refining is higher than that of refining into gasoline and then driven by gasoline engine. Therefore, it is beneficial to save energy and reduce carbon dioxide emissions.On the other hand, the application of electric vehicles can effectively reduce the dependence on oil resources, and can use limited oil for more important aspects. The electricity charged to the battery can be transformed by coal, natural gas, water power, nuclear energy, solar energy, wind power, tide and other energy sources. In addition, if the battery is charged at night, the peak power consumption can be avoided, which is conducive to the power grid to balance the load and reduce the cost.
Simple structure, convenient maintenance
Compared with internal combustion engine vehicle, electric vehicle has simple structure, less operation and transmission parts, and less maintenance work. When using AC induction motor, the motor does not need maintenance, more importantly, the electric vehicle is easy to operate.
High power and short driving range
At present, the technology of electric vehicle is not as perfect as that of internal combustion engine vehicle, especially the service life of power supply (battery) is short and the use cost is high. The battery's energy storage is small, and the driving distance after a charge is not ideal, and the price of electric vehicles is more expensive. But from the perspective of development, with the progress of science and technology, the problem of electric vehicles will be gradually solved. The advantages and disadvantages of electric vehicles will be gradually popularized, and its price and use cost will inevitably be reduced.
Power grid technology supporting development
The operation characteristics of electric vehicle battery replacement station, the key technology and control strategy of the replacement station as a distributed energy storage unit connected to the power grid; the screening principle, group method and system scheme of battery echelon utilization; the multi-purpose converter device of the replacement station; the integrated monitoring and control system of the replacement station and the energy storage station; and the integrated demonstration project of the replacement station and the energy storage station.
The characteristics of electric vehicle charging demand and the impact of large-scale electric vehicle charging on power grid; electric vehicle orderly charging control management system; electric vehicle orderly charging test system.
The control strategy and key technology of the interaction between electric vehicle and power grid; the intelligent charging and discharging motor of electric vehicle, intelligent vehicle terminal and the coordinated control system of electric vehicle and power grid interaction; the experimental verification system of electric vehicle and power grid interaction; the inspection and detection technology of electric vehicle charging and discharging facilities.
The new charging and discharging technology of electric vehicle; the intelligent charging and discharging control strategy and detection technology of electric vehicle; the key technology of interactive operation between charging facilities and power grid.
Large scale electric vehicle battery replacement technology, metering and billing, asset management technology; business model of charging facilities operation; operation management system construction scheme of intelligent charging and swapping service network based on Internet of things
